Valves VUVG, Plug-in

Universal directional control valves

The Festo VUVG Plug-in valves are solenoid valves in the plug-in connection format, identified by the 1T1L code in the type key. The 88-article range covers body sizes B10 and S10 with flat connection (F) as well as M5 and M7 ports. The plug-in concept allows tool-free insertion of the valve into a valve holder, with the electrical connection made via an integrated connector without a separate cable.

In the type key, ZT denotes a spring-sealed pneumatic outlet. The function range includes bistable 5/2-way (B52), spring-return 5/2-way (M52-MZT, M52-RZT) and 5/3-way mid-position types (T32C, T32H, T32U and P53C, P53E, P53U).

⚙ Plug-in concept (1T1L) - tool-free mounting in valve holder, integrated electrical connector

✓ Body sizes B10 and S10 - block and standard construction with flat connection (F)

⚡ ZT outlet seal - spring-sealed outlet prevents air loss when tubing is disconnected

📦 Ports F (flat), M5, M7 - three variants for different push-in and tubing configurations

Body size	Port	Functions	Connector
VUVG-B10	F (flat)	B52, M52-MZT, M52-RZT, P53C, P53E, P53U, T32C, T32H, T32U	1T1L
VUVG-S10	M5, M7	B52, M52-MZT, M52-RZT, P53C, P53E, P53U, T32C, T32H, T32U	1T1L

Typical applications: Modular valve arrangements with rapid tool-free valve exchange during servicing, handling robots and grippers with space-saving valve mounting directly on the end effector, and applications with frequently changed push-in tubing connections thanks to the ZT spring-sealed outlet.
