2 Arm Filtersystem 2x 100m³/h, 250W mit 2 Flexarmen je 1,5m und Düse 105mm - Quick QU6102A2-S2

Fine SMD rework wants the nozzle close above the board without blocking the view. The QU6102A2-S2 set pairs the 105 mm nozzles with the dual extraction of the 6102A2, and each of the two benches gets its own 100 m³/h.

Operating benefits

• 105 mm nozzle diameter, tighter capture and a clearer view of the joint than the 125 mm version.
• Two separate extraction ports at 100 m³/h each, both benches work independently.
• Four filter stages, stainless steel grid, pre-filter, HEPA medium filter and main filter, together rated 99.97 percent at 0.3 µm.
• 3000 Pa static pressure, so suction survives as the filters load.
• Filter change indicator and hour counter, the service date is read off rather than guessed.
• Brushless DC motor at 65 dB(A) maximum, built for continuous shift operation.
• Automatic operation with TS and TR series soldering stations, the unit switches with the station.

Technical data

Application, scope of delivery and compatibility

For paired benches in rework, repair and test areas where extraction has to sit close and aim precisely. Recirculating operation removes the ducting, so the unit stands between the seats. Scope of delivery, 6102A2 filter station, remote control with cable, mains cable, two 75 mm ESD flex arms of 1.5 m each and two 105 mm nozzles. For automatic operation the station connects to Quick soldering stations of the TS and TR series.
