Controller-Platine TS8-CON BOARD für Lötstation TS8/TS10+ - Quick QULPTS8
Replaces the TS8-CON BOARD and covers two stations at once, the TS8 and the TS10+. At 105 × 70 mm and 0.01 kg it is the smallest and lightest board in our Quick spare parts range. For sites running both station families.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
If a Quick TS8 or TS10+ no longer answers the controls, the controller board is the first candidate. At 105 × 70 mm and 0.01 kg the TS8-CON BOARD is a small control card that nevertheless carries the whole operating logic of the station.
Two stations, one controller board
- The supplier lists the board for the TS8 soldering station and for the TS10+, so one stock line covers both families.
- 105 × 70 mm, the smallest card format in this spare parts range.
- 0.01 kg, which keeps shipping light and makes holding several pieces easy.
- Original spare part designated TS8-CON BOARD, so the marking on the removed card confirms the match.
- Exchange instead of new purchase, keeping handpiece, housing and power supply of the station in service.
Applications
Repair of Quick TS8 and TS10+ stations in electronics manufacturing, repair services, laboratories and technical service. The low weight and small footprint make the card easy to keep in stock for several benches.
Technical data
| Brand | Quick |
|---|---|
| Part number | QULPTS8 |
| Part designation | TS8-CON BOARD |
| Component | controller board |
| Fits | Quick TS8 and TS10+ |
| Dimensions | 105 × 70 mm |
| Weight | 0.01 kg |
| Part type | original spare part |
| Scope of delivery | 1 controller board |
| Manufacturer | Quick |
| Manufacturer Nr. | QULPTS8 |
| GPSR manufacturer information | Bräunlich GmbH Am Heideberg 26, DE 06886 Lutherstadt Wittenberg, www.braeunlich-gmbh.com |
| Condition of article | New |
| Article authenticity | Original product |
Scope of delivery
One QULPTS8 controller board designated TS8-CON BOARD. It fits the Quick TS8 and the TS10+. Heating element, tips and cables are not part of the delivery.
Downloads
Datasheet
