A 45 degree bevel of Ø 1.0 mm puts a flat face on the pad instead of a single edge, which keeps the joint short and repeatable. Tip, heater and thermocouple form one cartridge, so the QUICK TS11 reaches 300 °C in 3 seconds from cold. Made for fine rework on boards, connectors and individual leads.
Kartuschenlötspitze TS11 angeschrägt Ø 1,0 mm - extrem schnelle Aufheizzeit - Quick TSS11-1C
QUICK
Original product
Net price (excl. VAT)
€6.30
Item
QCK-TSS11-1C
Manufacturer no.
TSS11-1C
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TSS11-1C
ConditionNew
Article
QCK-TSS11-1C
Frequently Bought Together
On fine pad rework the time goes into waiting for the tip, not into the joint itself. This cartridge tip takes the QUICK TS11 from 20 °C to 300 °C in 3 seconds because tip and heater are a single body.
Benefits
- 45 degree bevel at Ø 1.0 mm, the angled face sits flat and carries more heat than a needle of the same size.
- Heat-up time of 3 seconds from 20 °C to 300 °C with the TS11 station.
- Thermocouple sits right behind the working face, so control reacts at the joint rather than at the heater base.
- Working range 100 to 450 °C, enough headroom for lead-free alloys.
- Overall length 91 mm with a 3.4 mm to 3.5 mm shank, keeping the grip close to the work.
- Tool-free tip change, shape changes cost almost no bench time.
Technical data
| Tip shape | bevel, 45 degree face |
| Tip diameter | Ø 1.0 mm |
| Overall length | 91 mm |
| Shank diameter | 3.4 mm / 3.5 mm |
| Temperature range with TS11 | 100 to 450 °C |
| Heat-up time with TS11 | 3 seconds from 20 °C to 300 °C |
| Tip series | TSS11 |
| RoHS | compliant |
| Manufacturer number | TSS11-1C |
Applications
Soldering and rework on fine pads, single pins, connectors and printed circuit boards. The small bevel holds enough solder for short drag passes without touching neighbouring leads.
Scope of delivery and compatibility
1x cartridge soldering tip TSS11-1C. Fits the QUICK TS11 soldering station and the TSS11 tip holder.
| Manufacturer Nr. | TSS11-1C |
|---|---|
| Manufacturer | Quick |
| GPSR manufacturer information | Bräunlich GmbH Am Heideberg 26, DE 06886 Lutherstadt Wittenberg, www.braeunlich-gmbh.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
