Load Cell 40 kg - SAUTER CP 40-3P1

The SAUTER CP 40-3P1 converts loads up to 40 kg into a precise weighing signal at a single force introduction point. The anodised aluminium single point design carries the complete platform without extra bearings and fits price-computing scales, bench scales and platform scales with mounts up to 250 x 350 mm.

Benefits

• Approvable up to 3000 intervals (OIML R60, class C3): suitable for building legal-for-trade scales.
• Single point principle: one central force introduction carries the entire platform up to 250 x 350 mm.
• Anodised aluminium body: low own weight of 0,20 kg with a stable force path.
• Operating range -35 to 65 °C: covers chilled areas through to heated production.
• Higher class on request: versions to OIML R60 C4 or C5 are available.

Technical data

• Rated capacity (Max): 40 kg
• OIML R60 class: C3
• Verification interval: 3000 e
• Y value: 10000
• Force direction: Compression
• Maximum platform size: 250 x 350 mm
• Cable length: 0,4 m
• Connection: 4-wire
• Operating temperature: -35 to 65 °C
• Material: anodised aluminium
• Net weight: 0,20 kg

Applications

The load cell is used in industry and manufacturing, packaging, food and pharmaceutical applications, machine and plant engineering, and research and development.

Compliance and origin

EAN 4045761221222, customs tariff number 84239010, country of origin CN.
