Bending Ring Load Cell 130 kg, 1.3 kN, Stainless Steel - SAUTER CR 130-3P1
SAUTER CR 130-3P1 bending ring load cell made of stainless steel for compressive forces up to 1.3 kN or loads up to 130 kg. Verifiable to OIML class C3 with 3000 e and waterproof to IP68, for weighbridges, hanging scales, silo scales and test stands. It is listed as a measuring cell for the KERN CE HSN evaluation module and SAUTER FS 2 force gauges.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The SAUTER CR 130-3P1 measures weight and compressive forces up to 130 kg or 1.3 kN and delivers values for both force and mass. Its flat bending ring design in stainless steel with IP68 protection fits into weighbridges, hanging and silo scales as well as test stands.
Advantages
- Verifiable to OIML class C3: 3000 divisions, Y-value 10000 and combined error of 0.023 %.
- Force and mass: one cell for weighing tasks and compressive force measurement on test stands.
- IP68 protection: permanently waterproof for outdoor and agricultural use.
- Defined mounting: force application via thrust piece D=15 in bore (customer side), force dissipation via 3 x threaded hole M5.
- 4-wire connection with 3 m cable: connects to the KERN CE HSN or a SAUTER FS 2 force gauge.
Applications
Industry and manufacturing, agriculture and test stands, for example in weighbridges, hanging scales and silo scales.
Conformity and origin
EAN 4045761228139. Warranty 36 months.
Technical data
| Weighing capacity (Max) | 130 kg |
|---|---|
| Force measuring range (Max) | 1.3 kN |
| Design | bending ring |
| Direction of force | compression |
| Measuring application | force, mass |
| Combined error | 0.023 % |
| OIML class | C3 |
| Resolution (verifiable) | 3000 e |
| Y-value | 10000 |
| Rated output (nominal) | 1 mV/V |
| Protection | IP68 |
| Material | stainless steel |
| Connection | 4-wire |
| Cable length | 3 m |
| Force application | thrust piece D=15 in bore (customer side) |
| Force dissipation | 3 x threaded hole M5 |
| Manufacturer | Sauter |
| EAN | 4045761228139 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
