LED tube luminaire RL40LE-12 D, 4.5 W, 590 lm, clear, through-wired, 368 mm - Waldmann 113017000-00694174

For light lines built from short modules with maximum useful light, the RL40LE-12 D combines the clear tube with through-wiring. 590 lm at 4.5 W, 120° beam angle and approx. 118 lm/W, with several luminaires sharing one supply line.

Benefits

• Through-wired: several luminaires can be daisy-chained on one supply line
• Clear tube with 120° beam angle, approx. 93 % direct component, for maximum useful light on the workpiece
• Direct connection to 16-32 V DC machine voltage, no ballast in the luminaire
• IP67 protection and class III: dust-tight and protected against water jets for use inside machines
• Operation at ambient temperatures from -25 °C to 40 °C
• 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

• Machine tools and machining centres with limited space
• Control cabinets and control housings
• Test and assembly fixtures
• Continuous light lines from several daisy-chained luminaires

Installation and accessories

• Fastening via luminaire brackets from the accessory range (luminaire bracket, luminaire bracket set)
• Connection via QUICKON 3 built-in plug, side part with plug for onward wiring
• For mains voltage: operating device 100-240 V / 24 V DC with 30 W or 100 W, alternatively operating device 220-240 V / 24 V DC constant voltage IP67
