TUBELED_25 machine light 870 mm, 21.6W, daisy-chainable, IP67 - LED2WORK 154510-02
Daisy-chainable LED surface-mounted light for CNC machines and plants, with 3348 lm at just 23 mm mounting height. Several lights can be linked in series, and the aluminium housing with tempered glass reaches IP67 for OEM fitting and retrofit.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For long lighting runs on CNC machines and automated plants, the daisy-chainable TUBELED_25 in 870 mm length can be linked in series. It delivers 3348 lm at a mounting height of just 23 mm and fits slim into tight installation spaces, in original equipment or retrofit.
Key benefits
- Daisy-chainable for easy linking of several lights into long light lines.
- 3348 lm output at 155 lm/W for brightly lit work areas.
- Very slim, low profile of only about 23 mm for tight installation spaces.
- IP67 rating, dust- and liquid-tight for harsh machine environments.
- Shock- and vibration-resistant, up to 50 g shock, with over 100,000 h service life.
Applications
For continuous light lines illuminating work areas on CNC machines and automated plants, in original equipment or as a retrofit.
Technical data
| Model | TUBELED_25 daisy-chainable |
|---|---|
| Type | LED surface-mounted light for machines and plants |
| Light source | SMD LED |
| Power | ~21.6 W |
| Luminous flux | 3348 lm |
| Luminous efficacy | 155 lm/W |
| Light colour | 5700K 3-step MacAdam |
| Colour rendering (Ra) | >85 |
| Light distribution | Light Forming Technology |
| Supply voltage | 24 V DC ± 10% |
| Connection | M8 A-coded |
| Protection rating | IP67 |
| Protection class | III |
| Beam angle | 100° |
| Operating temperature | -30 °C to +55 °C |
| Service life | > 100,000 h (L80/B10) |
| Vibration resistance | 10 to 55 Hz (amplitude 0.35 mm) |
| Shock resistance | up to 50 g |
| Housing material | aluminium |
| Cover material | safety glass, 4 mm |
| Dimensions (H x W) | ~23 mm x ~28 mm, length 870 mm |
| Weight | 170 g |
| Dimmable | optional via accessory |
| Risk group (DIN EN 62471) | exempt group |
| Certifications | CE, UKCA, ETL Listed (5003529) |
| Made in | Germany |
| Manufacturer | LED2WORK |
| Manufacturer Nr. | 154510-02 |
| HS-Code | 94054239 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN EN 62471 |
| Control and dimming | Dimmable |
| Luminous flux (lumen) | 3348 lm |
| Power (W) | 21.6 W |
| Colour temperature | 5700K |
| Mounting type | Surface-mounted |
| Operating voltage | 24 V |
| Protection class (IP) | IP67 |
