LED tube luminaire RL 70 LE RL70LE-60 N, 22-26 V DC, polycarbonate, 2400 lm, 790 mm - Waldmann 113282000-00710514

For production and packaging lines handling food, the RL 70 LE RL70LE-60 N comes with a clear polycarbonate tube: 2400 lm, 75 lm/W and an overall length of 790 mm.

Benefits

• Runs on the 22-26 V DC machine supply in protection class III, with no control gear inside the luminaire.
• Clear polycarbonate tube with no risk of glass breakage, intended for areas close to food products.
• 2400 lm at 31.5 W and 75 lm/W, spread over a 736 mm light output length with a 100° beam angle.
• IP67 protection against dust and water jets, operating at ambient temperatures up to 40 °C.
• Light forming technology with diffuser for homogeneous, low-glare light with smooth transitions.
• LEDs for continuous operation without lamp replacement, length grid for 1:1 replacement of conventional Waldmann tube luminaires.

Applications

• Machines for areas close to food products
• Food processing and packaging lines
• Production lines where glass is unwanted

Installation and accessories

• Mounted with pipe clamp (accessory), e.g. luminaire bracket with rubber profile or stainless steel luminaire bracket for 70 mm diameter
• Mains connection: built-in plug, Connector, ST16/2 BS, side part A with screwed cable gland
• For mains operation: operating device 100-240 V to 24 V DC (30 W or 100 W) or 220-240 V to 24 V DC constant voltage (accessory)
