TUBELED_70 EVO LED machine light 1580 mm, 74W, 100°, IP67/IP69K - LED2WORK 156510-01
The 1580 mm TUBELED_70 EVO delivers an impressive 11394 lm at 74 W to light very large machine areas. Its IP67/IP69K rating and aluminium housing with safety glass shrug off dust, washdown and temperatures from -30 °C to +70 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For very wide work areas and large installations, the 1580 mm TUBELED_70 EVO provides continuous powerful illumination with 11394 lm at 74 W. At 155 lm/W, energy demand stays low.
Your benefits
- Very high light output: 11394 lm from 74 W, 155 lm/W efficacy.
- Fully sealed: IP67/IP69K rating, dust-tight and washdown-proof.
- Wide temperature range: operation from -30 °C to +70 °C.
- Long service life: over 100,000 h (L80/B10), low maintenance.
- Good colour rendering: Ra > 85 at 5700K for flicker-free light.
- Impact-proof: aluminium housing with safety glass, shock-resistant up to 50 g.
Applications
Suited to lighting very large machining centres, long machine fronts and production lines in harsh, wet or thermally demanding environments. Optionally dimmable, fixing hardware optional.
Technical data
| Model | TUBELED_70 EVO DC |
|---|---|
| Light source | SMD LED |
| Power | 74 W |
| Luminous flux | 11394 lm |
| Luminous efficacy | 155 lm/W |
| Light colour | 5700K 3-step MacAdam |
| Colour rendering (Ra) | > 85 |
| Supply voltage | 24V DC ± 10% |
| Connection | M12 A-coded, 3-pin |
| Protection rating (IP) | IP67/IP69K |
| Protection class | III |
| Beam angle | 100° |
| Operating temperature | -30 °C to +70 °C |
| Service life | > 100,000 h (L80/B10) |
| Material | aluminium, glass |
| Dimensions | 1580 mm x 70 mm x 59.5 mm |
| Weight | 4200 g |
| Risk group (DIN EN 62471) | exempt group |
| Certifications | CE, UKCA, ETL Listed (5003529) |
| Made in | Germany |
| Manufacturer | LED2WORK |
| Manufacturer Nr. | 156510-01 |
| HS-Code | 94054264 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN EN 62471 |
| Control and dimming | Dimmable |
| Luminous flux (lumen) | 11394 lm |
| Power (W) | 74 W |
| Colour temperature | 5700K |
| Operating voltage | 24 V |
| Protection class (IP) | IP69K |
