TUBELED_25 RGB-W IO-Link LED light 290mm, 7.2W white, IP67 - LED2WORK 154190-11

The TUBELED_25 RGB-W with IO-Link combines lighting and signalling and integrates directly into the machine controller: 1150 lm of white light for work lighting, red, green and blue for status signals, controlled over IO-Link, developed for equipment and machine tools of the IoT generation.

Key benefits

• IO-Link interface for direct integration into the machine controller.
• Lighting and signalling from one luminaire thanks to RGB-W LED clusters.
• White light 1150 lm at 7.2 W in 5000K (3-step MacAdam, Ra above 85) plus colour signals.
• Very slim, only approx. 23 mm mounting height at 290 mm length for tight installations.
• Shatterproof hard glass and aluminium housing, IP67, dust- and watertight.
• Long service life over 100,000 h (L80/B10).

Technical data

• Model: TUBELED_25 RGB-W IO-Link
• Design: surface-mounted LED light
• Light source: SMD LED RGB + W
• White power: approx. 7.2 W, 1150 lm (160 lm/W)
• Red power: approx. 2.2 W, 138 lm
• Green power: approx. 1.4 W, 252 lm
• Blue power: approx. 2.2 W, 84 lm
• White light colour: 5000K 3-step MacAdam
• White colour rendering (Ra): above 85
• Beam angle: 100°
• Supply voltage: 24V DC -5 %/+10 % (LEDs), 24V DC ± 25 % (IO-Link communication)
• Max. current draw: 350 mA (white), 120 mA (colours)
• Connection: M8 A-coded
• Protection rating: IP67
• Protection class: III
• Operating temperature: -30 °C to +55 °C
• Service life: over 100,000 h (L80/B10)
• Housing material: aluminium
• Cover material: safety glass
• Dimensions: 290 mm length, approx. 23 x 28 mm
• Weight: 30 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA, ETL Listed (5003529)
• Made in: Germany

Applications

Combined work lighting and IO-Link controlled status signalling on CNC machine tools, in automation and on networked equipment of the IoT generation.

Mounting accessories available as an option.
