LED tube luminaire RL70LE-108, 16-32 V DC, 2940 lm, 1362 mm, opal polycarbonate - Waldmann 113449000-00694640

The RL70LE-108 is the wide-beam version of the range: a 140° beam angle, 2940 lm at 30 W and 91 lm/W in 5700 K daylight white. The opal white polycarbonate tube diffuses the light softly, and the luminaire operates at ambient temperatures from -25 °C to 40 °C. The 16-32 V DC input range copes with fluctuating machine voltages, and the luminaire plugs in via a QUICKON 3 connector.

Benefits

• Opal white polycarbonate tube with IP67 protection for environments from -25 °C to 40 °C
• 2940 lm at 30 W power consumption, luminous efficiency 91 lm/W, 5700 K daylight white, CRI ≥ 80
• Diffuser and 140° beam angle for even light across 1251 mm of light output, luminance L65 ≤ 6400 cd/m²
• QUICKON 3 plug connection for 16-32 V DC, protection class III

Applications

• Production and packaging systems
• Textile and printing machines
• Machines in unheated areas down to -25 °C

Installation and accessories

• Mounting with lamp bracket (accessory)
• Connection via QUICKON 3 built-in plug on side part A
• Matching luminaire brackets, also with rubber profile or in stainless steel
• For mains operation: operating device 100-240 V / 24 V DC 100 W or constant voltage operating device 220-240 V / 24 V DC
