TUBELED_40 II RGB-W Power Machine and Signal Light 280 mm, 100° - LED2WORK 118190-01

The TUBELED_40 II RGB-W Power lights and signals from a single fixture: white LED chips deliver 1215 lm at 9,5 W for workplace illumination, while additional RGB chips signal status changes by flashing or colour change. The low-profile light is oil-resistant, chip-impact-proof and CNC-suitable.

Your benefits

• Lighting and signalling in one fixture saves installation space
• White illumination of 1215 lm at 9,5 W
• Signal function via RGB chips through flashing or colour change
• IP67/IP69K protection, oil-resistant and chip-impact-proof
• Low-profile build at just 29 mm, CNC-suitable
• Long service life of more than 100,000 h (L80/B10)

Technical data

• Model: TUBELED_40 II RGB-W Power
• Design: LED surface-mounted light
• Light source: SMD RGB-W Cluster LED
• Power white: ~9,5 W
• Luminous flux white: 1215 lm
• Colour rendering white (Ra): >80
• Power red: ~9 W
• Luminous flux red: 240 lm
• Power green: ~2,5 W
• Luminous flux green: 345 lm
• Power blue: ~9 W
• Luminous flux blue: 150 lm
• Beam angle: 100°
• Supply voltage: 24 V DC -10 %+7 % (RGB) / 24 V DC ±10 % (W)
• Connection: M12 A-kodiert, 5-pin
• Protection rating: IP67/IP69K
• Protection class: III
• Operating temperature: -30 °C to +60 °C
• Service life: > 100.000 h (L80/B10)
• Housing: aluminium
• Cover: Sicherheitsglas, sprungsicher
• Dimensions: 280 mm x 40 mm x 29 mm
• Weight: 400 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA, ETL Listed (5003529), D-Kennzeichnung
• Made in: Germany

Applications

For combined illumination and colour signalling of status changes in machine and equipment work areas.
