LED tube luminaire RL70LE-75 N, 230 V AC, 3100 lm, 790 mm, acrylic - Waldmann 113624000-00746151

For medium-sized working areas of machining equipment, the RL70LE-75 N delivers 3100 lm at 77 lm/W over an overall length of 790 mm. The clear acrylic (PMMA) tube is intended for wet environments exposed to powerful water jets. It connects directly to 230 V AC without a separate operating device, so it also suits systems that have no 24 V supply.

Benefits

• Light Forming technology with diffuser spreads the light across 736 mm of light output at a 100° beam angle, luminance L65 ≤ 17,000 cd/m²
• Clear acrylic (PMMA) tube with IP67 protection for wet environments exposed to powerful water jets
• 3100 lm at 40 W power consumption, luminous efficiency 77 lm/W, 5000 K neutral white, CRI ≥ 80
• Direct mains connection to 230 V AC, 50/60 Hz via series 272 connector, protection class I

Applications

• Machine tools with water jets in the working area
• Woodworking machines
• Integrated manufacturing and inspection systems

Installation and accessories

• Mounting with pipe clamp (accessory)
• Mains connection via series 272 connector, screwed cable gland on side part A
• Matching luminaire brackets, also with rubber profile or in stainless steel
• No additional operating device required
