Combination filter cassette complete H13A for LRA Jumbo - ULT 02.1.200
When the LRA Jumbo filter trolley starts losing extraction performance, this set replaces the entire filter train in a single service step. It contains an expanded metal prefilter, a change frame with the M5/F7 filter mat set and the H13A combination filter cassette rated at 99.95 percent particle separation. Coarse separation, prefiltration and main filtration therefore arrive matched and under one part number.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The LRA Jumbo filter trolley loses air volume as soon as its filter stages clog up. Combination filter cassette 02.1.200 is the complete replacement set for that unit and covers all three stages of the LRA filter train in one assembled unit.
Benefits
- Complete filter set for the LRA Jumbo filter trolley, one order number instead of several separate items
- Stage 1: expanded metal prefilter ULT 02.0.210 in knitted metal, a condensation filter for sticky aerosols, washable in an industrial washer and reusable
- Stage 2: change frame ULT 02.1.212 with the M5/F7 filter mat set, M5 rated ISO Coarse 85 % and F7 rated ISO ePM10 75 % to ISO 16890
- Stage 3: combination filter cassette ULT 02.1.202 in H13A version, H13 particulate filter to DIN EN 1822 at 99.95 % separation plus adsorption filter A with an activated carbon bed
- Matched to the nominal duty point of the unit, 80 m³/h at 1900 Pa
- Matched stages, so no frame dimensions need to be checked during servicing
Applications
Scheduled filter changes on mobile ULT filter trolleys extracting solder fumes, dust and light aerosols in electronics manufacturing, repair workshops or laboratory workstations. The set is typically replaced when the particulate filter indicator on the unit lights up red or the air volume at the extraction point noticeably drops.
Compatibility and scope of delivery
Suitable for filter trolleys of the LRA Jumbo series. Delivery includes the complete cassette consisting of ULT 02.0.210 expanded metal prefilter, ULT 02.1.212 change frame with the M5/F7 filter mat set and ULT 02.1.202 combination filter cassette H13A.
Recirculation is not permitted when extracting and filtering carcinogenic, mutagenic or reprotoxic substances.
Technical data
| Item number | WL20591 |
|---|---|
| Model | 02.1.200 |
| Manufacturer | ULT |
| Manufacturer item number | 02.1.200 |
| Order unit | piece |
| Filter type | complete filter set including main filter |
| Stage 1 | expanded metal prefilter, knitted metal, condensation filter |
| Stage 2 | change frame with filter mat M5 (ISO Coarse 85 %) and F7 (ISO ePM10 75 %) to ISO 16890 |
| Stage 3 | combination filter cassette H13A, H13 particulate filter to DIN EN 1822 and adsorption filter A |
| Particle separation rate | 99.95 % |
| Nominal duty point of the unit | 80 m³/h at 1900 Pa |
| Device series | LRA Jumbo |
| Weight | 6.8 kg |
| Weight | 6.800000 |
| Manufacturer Nr. | 02.1.200 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Filter class | H13 |
