Filter mat M5-01 prefilter series 200, 1 piece - ULT 02.0.552
This single M5-01 filter mat renews the first filter stage in the HFM TH system of the ULT ASD 200 and LAS 200 extraction units. It captures coarse dust and larger fume particles and therefore loads up faster than the stages behind it, which is exactly its purpose. Ordering one piece suits short notice replacement, while the same mat is also available as a pack of ten for planned maintenance.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The first filter stage is a sacrificial part: it clogs so that the main and activated carbon filters stay clear. The ULT 02.0.552 is precisely that M5-01 filter mat for the 200 series extraction units and is supplied as a single piece.
Benefits
- M5 filter class as the first stage of the HFM TH filter system
- Ordered individually, without committing to a full pack
- Original die cut that fits the filter compartment of the 200 series units
- Keeps the following stages clear and so stabilises the flow at the capture point
Applications
Retrofitting and immediate replacement on ASD 200 and LAS 200 solder fume and laser fume extractors, typically when extraction performance drops during a shift and the main filter is not yet due.
Compatibility and scope of delivery
The delivery consists of one M5-01 filter mat. It is part of the HFM TH filter system and fits the ASD 200 and LAS 200 units. For recurring demand the pack of 10 mats is the more economical option.
Technical data
| Item number | WL33139 |
|---|---|
| Model | 02.0.552 |
| Manufacturer | ULT |
| Manufacturer item number | 02.0.552 |
| Order unit | Piece |
| Content unit | 1 piece |
| Filter type | Prefilter |
| Filter class | M5 |
| Filter system | HFM TH |
| Device series | ASD 200, LAS 200 |
| Weight | 0.100000 |
| Manufacturer Nr. | 02.0.552 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | ISO 16890 |
