ESD high-resistance meter measuring kit digital - Warmbier Metriso 3000

The Warmbier Metriso 3000 measuring kit is a digital high-resistance meter for measuring point-to-point resistance and for checking the leakage resistance of people, footwear, mats and floor systems in the ESD protected area. With built-in memory for 50,000 readings, a USB interface and the ETC reporting software, it produces complete, archivable test reports for compliant ESD audits.

Key benefits

• Measures point-to-point and leakage resistance from 1 kOhm to 1.2 TOhm.
• Built-in data memory for 50,000 readings, read out via USB; ETC software for full test reports.
• Attachable probe captures temperature and humidity for meaningful measurements.
• Barcode scanner for automatic logging of measuring points before each measurement.
• Selectable high-resistance test voltages 10 V, 100 V and 500 V for compliant checks.
• Multilingual menu and battery operation for mobile use.

Technical data

• Low-resistance range: 0 to 10 kOhm
• High-resistance range: 1 kOhm to 1.2 TOhm
• Measuring current ohm range: 1 mA to 1.3 mA
• High-resistance test voltage: DC 10 V, 100 V, 500 V
• Display: digital readout
• Internal memory: 50,000 readings
• Interface: USB
• Menu languages: German, English, French, Spanish
• Operation: battery powered
• Electrodes: 2x Model 850 (2.27 kg each, 63.5 mm dia.), 1x hand electrode Model 45

Applications

• Leakage resistance testing of people, footwear and wrist straps.
• Point-to-point and resistance-to-ground measurements on mats, tables and floors.
• Documented, compliant ESD audits with automatic measuring-point logging.

Scope of delivery

• Digital high-resistance meter Metriso 3000
• Attachable temperature and humidity probe
• USB interface and PC software for Windows
• 2 measuring electrodes Model 850
• 1 hand electrode Model 45
• Measuring leads
• Operating manual (German, English, French)
• Factory calibration certificate
• Conductive carrying case with dissipative pink foam

Standards and compliance

Meets DIN EN 61340-4-1, DIN EN 61340-2-3 and DIN EN 61340-4-5 (IEC 61340).
