ESD high-resistance meter kit with electrodes digital - Warmbier Metriso 3000

The Metriso 3000 measuring kit with electrodes from Warmbier is a digital high-resistance meter for professional, traceable auditing of ESD protected areas. It measures point-to-point and leakage resistance of people, footwear, mats and floor systems over a particularly wide range from 1 kOhm to 1.2 TOhm and stores up to 50,000 readings for complete documentation.

Key benefits

• Very wide high-resistance range up to 1.2 TOhm, also for assessing highly resistive, insulating materials.
• Built-in data memory for up to 50,000 readings with USB readout to the PC.
• ETC reporting software to create and archive complete test reports.
• Attachable probe captures temperature and relative humidity together with the resistance value.
• Barcode scanner support for automatic logging of measuring points before measurement.
• Menu language German, English, French or Spanish; battery operation for mobile use.

Technical data

• Low-resistance range: 0 to 10 kOhm
• High-resistance range: 1 kOhm to 1.2 TOhm
• Measuring current ohm range: 1 mA to 1.3 mA
• High-resistance test voltage: 10 V, 100 V, 500 V DC
• Display: digital readout incl. barcode scanner
• Internal memory: up to 50,000 readings
• Interface: USB
• Environment capture: temperature and humidity (attachable probe)
• Power: battery operation
• Electrodes: 2x Model 870 (2.27 kg each, 63.5 mm dia., grey conductive contact rubber with silver particles), 1x hand electrode Model 45

Applications

• Documented, recurring testing of ESD workstations, coverings and floors.
• Audits with traceable measuring-point logging via barcode.
• Leakage resistance measurement on people and ESD footwear incl. climate log.

Scope of delivery

• Digital high-resistance meter Metriso 3000
• Attachable temperature and humidity probe
• USB interface and PC software for Windows
• 2 measuring electrodes Model 870 (2.27 kg each, 63.5 mm dia., grey conductive contact rubber with silver particles) with extension rod
• 1 hand electrode Model 45
• Measuring leads
• Operating manual (German, English, French)
• Factory calibration certificate
• Conductive carrying case with dissipative pink foam

Standards and compliance

Meets DIN EN 61340-4-1, DIN EN 61340-2-3 and DIN EN 61340-4-5 (IEC 61340).
