Permastat ESD bubble wrap, 2-layer, 75 µm, 300 mm wide, 100 m roll - Warmbier 3160.0300

Small parts, boards and connectors are cushioned economically from a narrow web, with little offcut at every cut. This dissipative Permastat film comes at 300 mm width and drains charges in a controlled way at 10^10 - 10^11 Ohm.

Benefits

• Dissipative setting with a typical bleeder resistance of 10^10 - 10^11 Ohm, so charges drain slowly.
• Two-layer polyethylene structure with smooth outer and inner layers, so the goods rest on a flat surface.
• Film thickness 75 µm, absorbing shocks while keeping the packaging light.
• Weldable, allowing bags and cushions to be made from the web in the size actually needed.
• Roll 300 mm wide and 100 m long, giving 30 m² per sales unit.
• Single-material polyethylene and therefore recyclable.

Technical data

Application

Inside the EPA as an interlayer in ESD containers, as wrapping for housings and instruments and as cushioning during in-house transport. The pink colour shows at the workbench that dissipative material is in use. Goods leaving the protected area call for shielding material.
