The 30 degree bend of the T80TZ004 pair keeps your hand out of the line of sight while the points still meet the pad squarely. At 0.4 mm width and 16 mm length they grip chip components in crowded areas of the board. Self-regulating 420-475 °C, for the SHP-TTZ handpiece.
Soldering tweezer tip pair bent 30 degrees sharp 0.4 mm T series - Thermaltronics T80TZ004
THERMALTRONICS Original product
Net price (excl. VAT)
€27.92
Item WL38387
Manufacturer no. T80TZ004
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.T80TZ004
ConditionNew
Article
WL38387
Frequently Bought Together
- This Item: €27.92
- Soldering tip hoof shape 60 degrees 3.3 mm drag soldering T series - Thermaltronics TM70DS525 €24.29
- Soldering tip bevelled 60° 1.8 mm short 350-398 °C T series - Thermaltronics TM70BS602 €13.25
Total price
Straight tweezer tips tend to hide the joint when you work under a microscope. The bent T80TZ004 version angles the handpiece by 30 degrees, so the view stays clear and the sharply tapered 0.4 mm points sit cleanly on the terminations.
Benefits
- Tip geometry bent by 30 degrees for an unobstructed view of the joint
- Sharp contour 0.4 mm wide for small chip parts and fine leads
- 16 mm tip length reaches between taller neighbouring components
- Curie point heating of the T series, self-regulating from 420 to 475 °C
- RoHS compliant and suitable for lead-free solder
Technical data
| Item number | WL38387 |
| Model | T80TZ004 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | T80TZ004 |
| Product series | T tweezer tip series, 420-475 °C |
| Tip type | Tweezers, pair of tips |
| Tip alignment | bent, 30 degrees |
| Temperature range | 420-475 °C |
| Tip width | 0.4 mm (0.02 in) |
| Tip length | 16 mm (0.63 in) |
| Suitable handpiece | SHP-TTZ |
| Suitable stations | TMT-5000S-1, TMT-5000S-2 |
| Dimensions with packaging (LxWxH) | 183 mm x 87 mm x 11 mm (7.2 in x 3.4 in x 0.4 in) |
| Weight | 0.1 kg |
| Order unit | piece |
| RoHS | compliant, lead-free |
Applications
Replacing chip resistors, capacitors, LEDs and small diodes, rework in tightly packed component fields, prototyping and laboratory work with visual control through a microscope or magnifier lamp.
Compatibility and scope of delivery
Fits the SHP-TTZ tweezer handpiece on TMT-5000S-1 and TMT-5000S-2. Supplied as one pair of tweezer tips.
| Manufacturer Nr. | T80TZ004 |
|---|---|
| Manufacturer | Thermaltronics |
| Weight | 0.100000 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
