Floor marking tile X-LOG with ESD logo, PVC, yellow RAL 1023, 497x497x5 mm, 1 piece - Ecotile 13.2321/5MM

EPA boundaries and entrances have to be recognisable at a glance. This 5 mm tile in the 497 × 497 mm format carries the ESD warning symbol on a yellow background (RAL 1023) and clicks straight into an Ecotile floor of the same thickness with the X-LOG joint, which the manufacturer calls X-Joint.

Advantages

• Marking set into the floor: ESD symbol on yellow RAL 1023, area 497 × 497 mm
• Laid like any other tile of the floor: X-LOG click joint, thickness 5 mm
• Smooth surface to match smooth 5 mm tiles
• Clear function: not ESD compliant, marking only with no discharge function

Technical data

Applications

Marking of EPA entrances, transitions between protected and unprotected areas and walkways in electronics production, test areas and stores. The tile does not dissipate charge, so a person standing on it is not grounded through the floor. Take this into account when positioning it.

Standards and quality

IEC 61340-5-1 requires EPA boundaries to be clearly identified. The tile provides this marking but is not part of the discharge path of the ESD floor.
