Festo CPE10-M1BH-3OLS-M5 (196854) Solenoid Valve
€112.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-196854
Manufacturer Nr.
CPE10-M1BH-3OLS-M5
Solenoid Valve
Frequently Bought Together
-
This Item:
€112.00Excl. 19% VAT , excl. Shipping Cost
-
Festo CPE18-M2H-5/3B-QS-10 (170299) Solenoid Valve
€23,332.00Excl. 19% VAT , excl. Shipping Cost
-
Festo CPE18-M3H-5/3B-QS-8 (170329) Solenoid Valve
€23,048.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 3/2 open monostable |
| Actuation type | Electrical |
| Build.width [mm] | 10 |
| Normal nominal flow [l/min] | 190 |
| Operating pressure [bar] | -0.9 to 10 |
| Construction set up | Piston pusher |
| Reset mode | Pneumatic spring |
| Permission | c UL us - Recognized (OL) |
| Maritime classification | see Certificate |
| Protection category | IP65 With Socket acc. to IEC 60529 |
| Nominal width [mm] | 4 |
| Sealing principle | Soft |
| installation position | arbitrary |
| Hand assist actuation | With Accessories ratcheting tentative |
| Control type | pilot operated |
| Control air supply | external |
| Flow direction | Not reversible |
| Valve space - labelling | Sign carrier |
| Überdeckung | positive Überdeckung |
| Shifting time off [ms] | 14 |
| Shifting time on [ms] | 14 |
| Power-on time | 100 % mit Haltestromabsenkung |
| Max. positive test impulse at 0 signal [µs] | 1.200 |
| Max. negative test impulse for 1 signal [µs] | 900 |
| Coil characteristic value | 24 V DC: 1,28 W |
| Permitted voltage oscillations | -15 % / +10 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Oscillation strength | Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Medium temperature [°C] | -5 to 50 |
| ambient temperature [°C] | -5 to 50 |
| Electrical connection | 2 pin |
| Fastening type | With throughway bores |
| Exhaust control connection 82 | M3 |
| Control air 12 connection | M3 |
| Pneumatic connection 1 | M5 |
| Pneumatic connection 2 | M5 |
| Pneumatic connection 3 | M7 |
| Material information | RoHs compliant |
| Seals material | NBR |
| Housing material | Aluminium die casting |
| Control pressure [bar] | 2.5 to 8 |
| control medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Manufacturer Nr. | CPE10-M1BH-3OLS-M5 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568159641 |
| Weight | 0.060000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
