Proximity Sensor SME-1-B - Festo 151668
Festo sensor for reliable monitoring of position, pressure or status in the pneumatic system.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo sensor for reliable monitoring of position, pressure or status in the pneumatic system. The key technical data of this genuine Festo article are listed below.
Technical data
| Design | Block structure |
|---|---|
| Material information | Copper and PTFE-free |
| Measurement principle | Reed magnetic |
| ambient temperature [°C] | -20 to 70 |
| Control output | Bipolar contact |
| Switching element function | NO contact |
| Reproducibility of the switching value | ± 0,1 mm |
| Switch on time [ms] | 0,5 |
| Max. output current [mA] | 1.000 |
| Max. switching capacity AC [VA] | 40 |
| Max. switching capacity DC [W] | 40 |
| Short circuit resistance | no |
| Overload resistant | Not available |
| Operating voltage range DC [V] | 0 to 200 |
| Reverse polarity protection | no |
| Electrical connection | 2-wire<br>cable |
| Fastening type | With Accessories |
| Product weight [g] | 130 |
| Housing material | PC<br>PET<br>TPE-O<br>Steel<br>Zinc pressure cast<br>Epoxy resin |
| Ambient temperature for moving cable placements [°C] | -5 to 70 |
| Protection category | IP67 |
| CE certificate (see declaration of conformity) | to EU low voltage directive |
| Operating voltage range AC [V] | 0 to 250 |
| Complies to standard | DIN EN 60947-5-2 |
| Switch off time [ms] | 0,03 |
| Max. switching frequency [Hz] | 500 |
| Max. output current AC [mA] | 1.000 |
| Max. output current DC [mA] | 1.000 |
| Voltage drop [V] | <= 0 V |
| Residual current [mA] | 0 |
| Connection outlet direction | along |
| Cable length [MTR] | 2,5 |
| Cable sleeve material | PVC |
| Torque [Nm] | 2,9 |
| Surge voltage strength [kV] | 4 |
| Degree of contamination | 3 |
| Weight | 0.11 kg |
| Manufacturer | Festo |
| Manufacturer Nr. | SME-1-B |
| EAN | 4052568116996 |
| HS-Code | 85365019 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Condition of article | New |
| Article authenticity | Original product |
| Material | Die-cast zinc |
| Norm | DIN EN 60947-5-2 |
| Series | SME |
| Protection class (IP) | IP67 |
| Temperature (max.) | 70 |
