Control Block VOFA-L26-T52-M-G14-1C1-APP - Festo 569819
FESTO
Original product
Net price (excl. VAT)
€677.66
Item
FES-569819
Manufacturer no.
VOFA-L26-T52-M-G14-1C1-APP
EN 60950
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VOFA-L26-T52-M-G14-1C1-APP
EAN4052568216467
Customs tariff number84812090
ConditionNew
Article
FES-569819
Frequently Bought Together
-
This Item:
€677.66
-
Solenoid Valve MHE3-MS1H-3/2O-1/8 - Festo 525167
€101.15
-
Solenoid Valve MHA1-M1LCH-2/2G-1.5-HC - Festo 557864
€38.08
Total price
Genuine Festo accessory for exact mounting, fastening and extension of the associated component. The key technical data of this genuine Festo article are listed below.
| Valve function | 5/2 monostable |
| Actuation type | Electrical |
| Build.width [mm] | 65 |
| Normal nominal flow [l/min] | 950 |
| Operating pressure [bar] | 3 to 10 |
| Construction set up | Piston pusher |
| Reset mode | Mechanical spring |
| Protection category | IP65<br>NEMA 4 |
| Permission | c UL us - Recognized (OL) |
| KC-mark | KC-EMV |
| CE certificate (see declaration of conformity) | to EU EMC directive<br>to EU machinery directive |
| Certified awarding point | UL MH19482 |
| Exhaust function | Can be throttled |
| Sealing principle | Soft |
| installation position | arbitrary |
| Complies to standard | EN 60947-5-2 |
| Hand assist actuation | none |
| Control type | pilot operated |
| Control air supply | Internal |
| Flow direction | Not reversible |
| Measurement principle | Inductive |
| Überdeckung | positive Überdeckung |
| Reverse polarity protection sensor | for all electrical connections |
| Safety function | Manipulation / start up protection<br>Reverse the movement |
| Performance Level (PL) | Manipulation safety, protection against unexpected start up to category 4 performance level e<br>Reverse the movement / to category 4 performance level e |
| Information about force dynamic sampling | Switching frequency at least 1x per week |
| Signal condition display | With Accessories |
| Switching position query | Idle position with sensor |
| Noise status indicator | LED |
| Control pressure [bar] | 3 to 10 |
| Shifting time off [ms] | 56 |
| Shifting time on [ms] | 22 |
| Valve - sensor switching time on [ms] | 60 |
| Valve - sensor switching time off [ms] | 11 |
| Power-on time | 100 % |
| Max. positive test impulse at 0 signal [µs] | 1.000 |
| Max. negative test impulse for 1 signal [µs] | 800 |
| Control output | PNP |
| Coil characteristic value | 24 V DC: 1,8 W |
| Permitted voltage oscillations | -15 % / +10 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Oscillation strength | Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistant class KBK | 0 - No corrosion stressing |
| Max. magnetic error field | 60 mT |
| Medium temperature [°C] | -5 to 50 |
| Sound level [dB(A)] | 85 |
| Protect against direct and indirect contact | Schutzklasse nach EN60950/IEC 950<br>Funktionskleinspannung mit sicherer Trennung (PELV) |
| control medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| ambient temperature [°C] | -5 to 50 |
| Nominal usage height above normal null | 1000 m to VDE 0580 |
| Product weight [g] | 1.138 |
| Operating voltage range DC sensor [V] | 10 to 30 |
| Short circuit resistance sensor | Cycling |
| Empty run sensor [mA] | <= 10 mA |
| Max. output current sensor [mA] | 200 |
| Max. switching frequency sensor [Hz] | 5.000 |
| Residual ripple sensor | ± 10 % |
| Sensor voltage drop [V] | <= 2 V |
| Electrical connection | Wiring diagram Form C acc. to EN 175301-803<br>without protective earthing conductor<br>acc. to EN 175301-803 |
| Sensor connection | M8x1<br>3 pin<br>Plug |
| Fastening type | With throughway bores |
| Pressure gauge connection | G1/4 |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G1/4 |
| Pneumatic connection 3 | G1/4 |
| Pneumatic connection 4 | G1/4 |
| Pneumatic connection 5 | G1/4 |
| Material information | RoHs compliant |
| Seals material | FKM<br>HNBR<br>NBR |
| Housing material | PA<br>Aluminium die casting |
| Screws material | Steel<br>zinc plating |
| Switching element function | NC contact |
| Norm | DIN EN 175301-803, VDE 0580, DIN EN 60947-5-2 |
|---|---|
| Certification | EN 60950 |
| Operating conditions | EN 60068-2-27, EN 60068-2-6, ISO 8573-1 |
| Manufacturer Nr. | VOFA-L26-T52-M-G14-1C1-APP |
| Manufacturer | Festo |
| EAN | 4052568216467 |
| Weight | 1.300000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 50 |
| Material | Aluminium |
| Betriebsdruck max [bar] | 10.000000 |
| Pneumatic connection | G1/4 |
| Protection rating | IP65 |
| Dichtmaterial | FKM, HNBR, NBR |
| Medium | Compressed air |
| Funktion | 5/2 monostable |
| Durchfluss [l/min] | 950 |
| Corrosion resistance class CRC | 0 - No corrosion stressing |
| Mounting position | arbitrary |
| Design | Piston pusher |
| Position sensing | No |
| Actuation type | Electrical |
