ESD safety low shoe CX 50 black S1 SRC, City Style, width 10, black - Atlas 29700

Not every ESD workplace looks like a shop floor. The CX 50 black from the City Style range keeps the person, shoe and floor resistance below 100 megohms to DIN EN 61340-5-1 while looking like a business shoe, which makes it wearable for service, sales and quality assurance.

Why this model

• Charge dissipation to DIN EN 61340-5-1. ESD footwear keeps the resistance of the person, shoe and floor chain below 10 to the power of 8 ohms, that is below 100 megohms, measured to DIN EN 61340-5-1. Charge on the wearer drains in a controlled way instead of building up and discharging into an assembly.
• Toe protection rated at 200 joules. The steel toe cap withstands 200 joules of impact energy and 15 kN of compression under EN ISO 20345, which corresponds to a 20 kg object falling one metre.
• Cushioning without a workshop look. The MPU sole technology with the MPU REBOUND SYSTEM and the replaceable insole with heel cushioning absorb the impact on hard industrial floors and on office flooring alike.
• Foot climate across the shift. The SportLine upper is an air permeable textile fabric with a hydrophobic finish, so it repels water and dries quickly. The aktiv-X functional lining regulates moisture, does not stain and resists chafing. Together with the clima-stream concept this keeps the temperature inside the shoe in a narrow band.
• Fit instead of compromise. Width 10 is the Atlas standard width and is already cut wider than usual. Wearers who need more volume find the same model in the Atlas multi-width system.
• Orthopaedic insoles without losing approval. The model is released for orthopaedic insole fitting under DGUV rule 112-191. The marking inside the shoe is decisive.

Technical data

Applications

The shoe suits workplaces where ESD protection and a restrained appearance have to go together. Typical settings are quality assurance and test bays, technical sales and on site service, laboratories, data centres and control rooms, and the walk between office and production. For permanently wet areas or work with penetration risk, choose a higher protection class.

Standards and conformity

EN ISO 20345:2012 S1 SRC, tested and certified by the notified bodies TÜV Rheinland Product Safety GmbH, Cologne (ID 0197) and PFI Prüf- und Forschungsinstitut Pirmasens (ID 0193). EU type examination certificate under module B, no. 2107206-01-86. Personal protective equipment of risk category II under Regulation (EU) 2016/425. ESD marking to DIN EN 61340-5-1. Released for orthopaedic insole fitting under DGUV rule 112-191. Manufacturer is ATLAS GmbH und Co. KG, Frische Luft 159, 44319 Dortmund, Germany.

Protection class S1 means a closed heel area, energy absorption in the heel, antistatic properties and a fuel resistant outsole. That is the right class for dry indoor areas such as production, test bays and warehousing. Antistatic under EN ISO 20345 means a through resistance between 10 to the power of 5 and 10 to the power of 9 ohms. The lower limit of 0.1 megohms set by DGUV rule 112-191 also limits the risk of current passing through the body when working at up to 230 volts.

Sizes

Available in EU sizes 39 to 48 in width 10 (standard). The size is selected in the basket and one pair is supplied.
