ESD Ball Joint Vise SPANNFIX Set with Earth Bonding Plug and Grounding Cable - Bernstein 9-205-ESD-SET1
This ESD set combines the ball joint vise SPANNFIX for clamping with an earth bonding plug and a 1.8 m grounding cable (1 megohm) for direct connection to the grounding point. The vise holds with 1470 N clamping force at a 70 mm clamping width, and the dissipative ESD coating (10^7 to 10^8 ohm) makes it EPA suitable.
Net
excl. VAT
€204.06
Item
BS-9-205-ESD-SET1
Manufacturer no.
9-205-ESD-SET1
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A complete ESD workstation needs not only a dissipative vise but also a reliable link to the grounding point. This set supplies the ball joint vise SPANNFIX for clamping together with an earth bonding plug and a 1.8 m grounding cable, matched and ready to use.
Advantages
- Ball joint vise with 1470 N clamping force at a 70 mm clamping width, rotatable 360° and tiltable by ± 45°
- Dissipative black ESD powder coating at 10^7 to 10^8 ohm for EPA-suitable workstations
- Earth bonding plug with 2x10 mm and M5 connection for flexible mounting at the grounding point
- 1.8 m grounding cable with 1 megohm protective resistor and two 10 mm push studs
- Clamp fastening without drilling, suitable for table top thickness up to 80 mm
Application
For soldering, testing and assembly workstations in electrostatically protected areas (ESD workplace / ESD protection zone) where the vise and its grounding connection are needed together.
Standards and Delivery Data
- EPA suitable for electrostatically protected areas
- EAN 4250838529747
- Customs tariff number 82057000
- Country of origin Germany
Technical data
| Feature | Value |
|---|---|
| Ball joint | Rotatable 360°, steplessly lockable quick release, Made in Germany |
| Mounting | Clamping to the workbench, table thickness max. 80 mm |
| Jaws | 50 mm ESD plastic with grip |
| Clamping width | 70 mm |
| Clamping depth | 38 mm |
| Clamping force | 1470 N |
| Tilt angle | ± 45° |
| Accessories | Spare jaws Art. 9-900-E50-ESD (pair) |
| Material | Cast aluminum with black ESD powder coating, dissipative 10^7 to 10^8 ohm |
| Dimensions | approx. 310 x 170 x 75 mm |
| Weight | 1550 g |
| Maximum torque | ball dia. 40 mm approx. 24 Nm, ball dia. 60 mm approx. 100 Nm |
| Manufacturer | Bernstein |
| Manufacturer Nr. | 9-205-ESD-SET1 |
| EAN | 4250838529747 |
| HS-Code | 82057000 |
| GPSR manufacturer information | BERNSTEIN Werkzeugfabrik Industriehof Trecknase 1 DE-42897 Remscheid www.bernstein-werkzeuge.de |
| Condition of article | New |
| Article authenticity | Original product |
| ESD version | ESD (antistatic) |
Scope of delivery
