The centering pin positions and orients workpiece pallets in the PE 2/XP positioning unit of the TS 2plus transfer system. The flat-sided design provides defined, repeatable alignment. It is used as a component of the positioning unit.
Centering Pin D12x30, Flat-Sided, for PE 2/XP Positioning Unit - Bosch Rexroth 3842242396
BOSCH REXROTH Original product
Net price (excl. VAT)
€20.60
Item BRR-3842242396
Manufacturer no. 3842242396
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842242396
Country of originGermany
Customs tariff number73182400
ConditionNew
Article
BRR-3842242396
Frequently Bought Together
The centering pin is used for precise positioning and orientation of workpiece pallets in the PE 2/XP positioning unit of the Bosch Rexroth TS 2plus transfer system. The flat-sided design provides defined and repeatable alignment.
- Repeatable positioning thanks to the flat-sided form
- Suitable as a component of the PE 2/XP positioning unit in the TS 2plus
- Compact size with 12 mm diameter and 30 mm length
Technical data
| Diameter [D] | 12 mm |
| Length [l] | 30 mm |
| Design | flat-sided |
| Weight | 0.018 kg |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842242396 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 18.000000 |
| HS-Code | 73182400 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
