Statfree DLR Dissipative 2-Layer Rubber Roll, 2.5 mm x 1.9 m x 10 m, Light Grey - Desco 210926

The Statfree DLR is a dissipative, two-layer rubber matting for ESD protected areas. It can be used as a large-area floor covering or as a working surface mat and dissipates electrostatic charges to ground in a controlled way. The coloured top side is static dissipative, the black underside is conductive.

Benefits

• Dual-layer rubber, static dissipative coloured side or conductive black side
• Suitable as both working surface and floor matting
• Resistance to ground Rg 10⁶ to 10⁸ Ω, meets the EN 61340-5-1 flooring limit
• Resistant to cleaning agents normally used for maintenance per EN 423

Technical data

• Material: dual-layer rubber
• Size: 2.5 mm x 1.9 m x 10 m (roll)
• Thickness: 2.5 mm
• Colour: light grey
• Point-to-point resistance Rp-p: 10⁶ to 10⁹ Ω per IEC 61340-4-1
• Resistance to ground Rg: 10⁶ to 10⁸ Ω
• Hardness: 85 ± 5 shore A per ISO 7619
• Abrasion 5 N (ISO 4649, method A): less than 200 x 10³ mm³
• Area weight: 2.7 kg/m²

Application

Dissipative floor and working surface covering in ESD protected areas. Where flooring is used to ground personnel handling ESDS, the system requirements of EN 61340-5-1 for the person/footwear/flooring system apply.

Standards and compliance

Tested per IEC 61340-4-1, meets the EN 61340-5-1 flooring limit.
