Statfree DLR Dissipative 2-Layer Rubber Roll, 3.5 mm x 1.22 m x 10 m, Dark Grey - Desco 210927

Large ESD protected areas need a floor that carries charge from people and trolleys to ground in a controlled way and copes with daily traffic. Statfree DLR two-layer rubber reaches a resistance to ground Rg of 1 x 10⁶ to 1 x 10⁸ ohms per IEC 61340-4-1, inside the EN 61340-5-1 flooring limit. The roll measures 3.5 mm x 1.22 m x 10 m.

Key benefits

• Two-layer construction: static dissipative dark grey top, conductive black base that forms the path to the ground point.
• Controlled discharge: Rg 1 x 10⁶ to 1 x 10⁸ ohms, Rp-p 1 x 10⁶ to 1 x 10⁹ ohms.
• Takes heavy use: 3.5 mm rubber at 85 ± 5 Shore A, suitable where chairs with casters are used.
• Wear resistant: abrasion per ISO 4649 below 200 mm³, resists heat and chemicals.
• Easy care: low-reflection surface, resistant to standard cleaning agents per EN 423.

Applications

Dissipative floor covering for EPAs, walkways and production stations, also usable as a work surface mat. Where personnel are grounded through footwear and flooring, the total system of person, footwear and floor must stay below 1 x 10⁹ ohms with body voltage under 100 V. Clean with an ESD mat cleaner such as Reztore, as silicone-based cleaners leave an insulating film.

Standards

Resistance tested per IEC 61340-4-1, meets the EN 61340-5-1 flooring limit. Grounding is made via a floor ground point and ground cord.
