Emit Overhead Zero Volt Ionizer, 3 Fans, Stainless Steel, 220 V, No Power Cord - Desco 50672

Circuit board materials, films and plastic housings cannot be grounded, so their charge travels with them to the component. The Emit Overhead Zero Volt Ionizer neutralizes them from above without taking up bench space. Three fans cover about 61 x 152 cm while the offset voltage stays within ± 3 V.

Key benefits

• Very low offset voltage of ± 3 V thanks to steady-state DC ionization with closed-loop feedback from an internal sensor grill
• Discharge time below 3 seconds at a distance of 46 cm
• Dedicated high-voltage module and balance setting per fan, each adjustable with a charged plate monitor
• 9 fan speeds from 92 to 142 l/s, higher speeds give faster neutralization
• LED display for address, balance, fan speed and maintenance codes, audible alarm with adjustable threshold from AL 5 to AL 25
• Key switch prevents unintended changes, stainless steel housing and tungsten emitters suit clean areas

Applications

Electronics manufacturing, calibration, test and repair stations, and workstations with little free bench space. The ionizer hangs above the work area and needs an unobstructed airflow path.

Standards

Suited to ESD control programs per ANSI/ESD S20.20 and IEC 61340-5-1. Ionization supplements the grounding of people and conductors but does not replace it. Check balance and discharge time regularly with a charged plate monitor and clean the emitters on a fixed schedule.
