Vertical arm for RK-10 stand - Dino-Lite RK-10-VX

Dino-Lite ✓ Original product Brand new Made in Taiwan

The Dino-Lite RK-10-VX vertical arm raises the microscope on the stand and, according to the manufacturer, increases the usable working distance, for tall objects for example. It fits the RK-10A, RK-10FS, RK-06A and RK-06F stands. For the compact RK-04 and RK-05 stands there is a separate vertical arm, the RK-05-VX.

Net
€26.40
excl. VAT
Item RK-10-VX
Manufacturer no. RK-10-VX
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A tall housing, a populated assembly or a workpiece in a vise does not always fit under the stand. The Dino-Lite RK-10-VX is a vertical extension that sets the microscope higher above the work surface. That leaves more distance between microscope and bench.

The metal arm is 160 mm tall and weighs 109 g. It mounts on stands of the RK-10 and RK-06 series. Focus and fine adjustment are still handled by the stand.

What it does in practice

  • Get tall objects under the microscope without changing stands.
  • More room above the object for tools and hands, for example when soldering under the microscope.

Works with

Microscopes: every Dino-Lite handheld microscope that sits in the stand's holder. That covers the Edge, Edge PLUS, Edge 3.0, DinoConnect (AF) and Basic series as well as the AD models.

Stands: the manufacturer approves the RK-10-VX for the RK-10A, RK-10FS, RK-06A and RK-06F stands (sold in the US as RK-06FA). The manufacturer does not list the arm for the compact RK-04, RK-04F, RK-05 and RK-05F stands.

Holders: the RK-10A and RK-06F ship with the HD-P1 holder. The HD-M2A and HD-M1 are metal alternatives with a 10 mm mount.

Not suitable: the HD-M2B holder has a 1/2 inch mount and, according to the manufacturer, does not fit RK stands.

Combines with: the RK-10-EX (additional arm, included with the RK-10A, RK-10FS and RK-06F), RK-10-FX (gooseneck arm) and RK-10-PX2 (XY positioning arm), approved by the manufacturer for the same stands. For stands with a 10 mm rod in the RK-04, RK-05 and RK-06 series the manufacturer offers the RK-05-VX vertical arm.

Technical data

PropertyValue
TypeVertical extension arm for stands
Dimensions70 mm (L) x 10 mm (D) x 160 mm (H)
Weight109 g
MaterialMetal (aluminium)
Regulatory approvalRoHS
Warranty2 years manufacturer warranty
Package contentsVertical arm (no stand, no microscope holder)
ManufacturerDino-Lite
Manufacturer Nr.RK-10-VX
EAN4712805475278
HS-Code90119090
GPSR manufacturer informationA1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment, info@esd.equipment
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureTaiwan

Downloads

Datasheet

User Manual

Brochure
