Metal universal holder 10 mm for MS-W1, RK-06 and RK-10 - Dino-Lite HD-M2A
The Dino-Lite HD-M2A metal holder takes any Dino-Lite handheld microscope and mounts on the stand rod through 10 mm holes, either vertically or horizontally. According to the manufacturer it fits most Dino-Lite stands, for example the RK-10A, RK-06A and RK-06F. Not suitable for the RK-04, RK-04F, RK-05 and RK-05F.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Dino-Lite HD-M2A connects the handheld microscope to the stand. A screw lock clamps the microscope in the metal holder and releases it again when you want to take it off.
The rod mount is 10 mm in diameter. The 10 mm mounting holes let you attach the holder to the rod in a vertical or a horizontal orientation. It fits the precision stands of the RK-06 and RK-10 series, but not the compact RK-04 and RK-05 stands.
What it does in practice
- Mount it on the rod vertically or horizontally.
- A screw lock for attaching and removing the microscope.
- Low profile metal holder, 18 mm high and 50 g.
Works with
Microscopes: according to the manufacturer, every Dino-Lite handheld microscope. That covers the Edge, Edge PLUS, Edge 3.0, DinoConnect (AF) and Basic series as well as the AD models.
Stands: according to the manufacturer, most Dino-Lite stands with a 10 mm rod, including the RK-10A, RK-10F, RK-10FS, RK-06A, RK-06-AE and RK-06F.
Not suitable: the compact RK-04, RK-04F, RK-05 and RK-05F stands. For these the manufacturer offers the HD-M1 metal holder and the HD-P2 plastic holder, which fit all Dino-Lite stands.
Combines with: HD-M2B, the version with a 1/2 inch mount for optical table posts. It does not fit RK stands.
Technical data
| Property | Value |
|---|---|
| Type | Metal microscope holder with screw lock |
| Rod mount | 10 mm, vertical or horizontal |
| Dimensions | 85 mm (L) x 39 mm (W) x 18 mm (H) |
| Weight | 50 g |
| Material | Metal |
| Regulatory approval | RoHS, CE |
| Warranty | 2 years manufacturer warranty |
| Package contents | 1 holder |
| Manufacturer | Dino-Lite |
| Manufacturer Nr. | HD-M2A |
| EAN | 4711203830689 |
| HS-Code | 90119090 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment, info@esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Taiwan |
