ESD Electric Screwdriver 0.03-0.29 Nm - Sehan EF030-E
The Sehan EF030-E is an electric screwdriver with a torque range of 0.03-0.29 Nm and a dissipative ESD design. Lever start with clutch shut-off and switchable high/low speed deliver repeatable fastening results in electronics assembly.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Sehan EF030-E is an ESD-safe electric screwdriver for fine assembly with a torque range of 0.03-0.29 Nm. Torque is infinitely adjustable and reliably limited by the automatic clutch shut-off.
Features
- Dissipative ESD housing and grounded bit for use at EPA workstations
- Infinitely adjustable torque from 0.03-0.29 Nm
- Clutch shut-off for even and repeatable fastening results
- Switchable high/low speed with 700 / 1,000 rpm
- Lever start for controlled positioning of the screw
- Runs on the KT-38D controller, to be ordered separately
Application
The EF030-E is designed for electronics and fine assembly, series assembly in production and medical technology applications. The torque range covers screws from M0.6-M3.0.
Compatibility
The EF030-E runs on the KT-38D controller with 230 VAC mains supply, soft start, speed preselection and a 5-pin connection, which is ordered separately. Accessories include the protective cap 587-0003 for the torque adjustment ring, the vacuum attachment 901-0052, the connection cables 518-0029, 518-0078, 518-0032 and 518-0031 as well as the SCOUT II screw counter, which works only with the KT-38D or FT-40D.
Technical data
| Torque | 0.03-0.29 Nm |
|---|---|
| Speed | 700 / 1,000 rpm |
| Drive/bit | 4.00 mm half-round |
| Start type | Lever start |
| Motor | Carbon brush motor |
| Operating voltage | 20/30 VDC |
| Weight | 0.24 kg |
| Length | 195 mm |
| Grip diameter | 30 mm |
| Screw size | M0.6-M3.0 |
| ESD | yes, dissipative |
| Manufacturer | Sehan |
| Manufacturer Nr. | EF030-E |
| HS-Code | 84672985 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | South Korea |
| ESD version | ESD (antistatic) |
| Min torque (Nm) | 0.03 |
| Max torque (Nm) | 0.29 |
| Max speed (rpm) | 1000 |
| Start system | Lever start |
| Drive | H4 (4 mm hexagon) |
| Brushless motor | No |
