Phillips bit No. 0 in the long version, 64 mm, for a 4 mm bit holder - Delvo DLB2125
The long version of the No. 0 Phillips bit with a 64 mm overall length. It bridges counterbores and tall housing walls where the 44 mm bit no longer reaches the screw head.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A housing wall 20 mm high is enough to make a short bit miss the screw head. With a 64 mm overall length this size No. 0 Phillips bit clears such edges and still sits square on the screw.
Benefits
- 64 mm overall length as reach reserve over the 44 mm version
- 11 mm blade length for full engagement in the No. 0 cross recess
- Hardness grade H and a special alloy with controlled heat treatment
Applications
Screw joints in counterbored holes, deep housings and positions that are hard to reach in equipment and apparatus construction.
Matching accessories
Runs on Delvo electric screwdrivers with a 4 mm holder such as DLV-7410-BME6, DLV-7420A BME6 or DLV-7331-BME6. For screwdrivers with a 1/4 inch holder there is the ADA-HR4-D63 adapter, and for holding the screw the ring magnets MAG-RING-4,7 and MAG-RING-6,0. The same size in the short version is DLB2124.
Technical data
| Profile | Phillips cross recess |
|---|---|
| Size | No. 0 |
| Blade length | 11 mm |
| Overall length | 64 mm |
| Shank | 4 mm dia., half round (HR), collar at 20 mm |
| Drive | H4 (4 mm hex) |
| Model series | NK4D |
| Hardness grade | H |
| Material | Special alloy by Nitto Kohki |
| Weight | 0.100000 |
| Manufacturer | Delvo |
| Manufacturer Nr. | DLB 2125 |
| HS-Code | 82079030 |
| GPSR manufacturer information | DELVO Gottlieb-Daimler-Str. 10 DE-71144 Steinenbronn www.nitto-kohki.eu |
| Condition of article | New |
| Article authenticity | Original product |
| Sales unit | Stück |
| Overall length [mm] | 64.000000 |
| Shank outer diameter [mm] | 4.000000 |
| Drive | H4 (4 mm hexagon) |
