N2 Upgrade Kit for i-Tool and i-Tool nano Soldering Iron - Ersa 0109IN2-UKIT
N2 upgrade kit that extends the i-Tool soldering iron with a nitrogen feed. Inerting the joint with nitrogen significantly reduces oxide formation during soldering. An existing nitrogen supply is required.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Ersa N2 upgrade kit extends the i-Tool soldering iron with a nitrogen feed. During soldering, oxides form when oxygen from the ambient air combines with the solder. By inerting the joint with nitrogen (N2), this effect is significantly reduced. Ersa developed this set to enable N2 inerting during hand soldering with the i-Tool.
An existing nitrogen supply is required to operate the N2 feed. Suitable for soldering tips up to approx. 5 mm that nitrogen can flow through.
Technical data
| Type | N2 upgrade kit (nitrogen feed) |
|---|---|
| Function | Inerting the joint with nitrogen to reduce oxide formation |
| Requirement | Existing nitrogen supply |
| Compatible with | i-Tool (0100CDJ), i-Tool nano (0120CDK) |
| Conditionally compatible | i-Tool pico (0130CDK), additional 0A52 required |
| Suitable soldering tips | up to approx. 5 mm |
| Dimensions | 300.5 x 70 x 45 mm |
| EAN | 4003008102017 |
| Weight | 0.1 kg |
| Manufacturer | Ersa |
| Manufacturer Nr. | 0109IN2-UKIT |
| GPSR manufacturer information | Ersa GmbH, Leonhard-Karl-Straße 24, DE-97877 Wertheim, www.kurtzersa.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
Downloads
Datasheet
Declaration of Conformity
