i-CON Vario 2 MK2 ESD 2-Channel Soldering and Hot-Air Station with i-Tool 150 W and AIR-TOOL 200 W - Ersa 0ICV2005AI

The Ersa i-CON Vario 2 MK2 is an ESD-safe multi-channel soldering and hot-air station that gives the professional user two soldering tools usable at the same time. Alongside the ergonomic i-Tool AIR S hot-air iron (200 W), the 150 W i-Tool can be run for classic soldering, or alternatively the Chip Tool Vario desoldering tweezers (80 W). The compact, ESD-safe supply unit offers the simple, clear operation typical of the i-CON family, interfaces to Ersa fume extraction units and preheating plates, and safe configuration via a microSD memory card.

Scope of delivery

• Electronic station, antistatic, 200 W, air flow 2-20 l/min (0ICV2035A)
• i-Tool AIR S hot-air iron 200 W, 50-550 °C (0470ERJ)
• Hot-air nozzle, 3.5 mm diameter (0472ER)
• i-Tool soldering iron 150 W (0105CDJ) with chisel tip, 1.6 mm (0142CDLF16)
• Holder stand for i-Tool AIR S (0A55)
• Holder stand for i-Tool (0A59)

i-Tool AIR S

The slim, lightweight handpiece carries a 200 W heating cartridge and allows low-fatigue work on a wide range of SMD components. The hot-air volume is set directly on the handpiece and shown on the display of an i-CON Vario 2 or 4 (2 to 20 l/min). Different nozzles ensure optimal heating of the components. A motion sensor switches the hot air off automatically after a programmable time during work breaks, and a light sensor in the handpiece turns the tool on and off.

i-Tool

The i-Tool is an extremely light, powerful fine soldering iron with a broad range of economical long-life tips. 150 W of power deliver the fastest heat-up and recovery behaviour; a process-window alarm, energy power levels and an automatic stand-by sensor provide a high level of process control. The integrated Tip'N'Turn bayonet lock enables quick, simple tip changes and improves performance by 20-25 % compared with a screw connection. Standby power consumption approx. 25 W.

Technical data
