i-CON Vario 2 MK2 Soldering and Hot-Air Station, ESD 2-channel with X-Tool vario 150 W and i-Tool AIR S 200 W - Ersa 0ICV2005AXV

Ersa ✓ Original product Brand new Made in Germany

ESD 2-channel soldering and hot-air station i-CON VARIO 2 MK2 with vacuum pump, X-Tool vario desoldering iron (150 W) and i-Tool AIR S hot-air tool (200 W). Run two tools at once with auto-standby and easy i-OP operation for professional soldering and desoldering.

Net
€1,801.51
excl. VAT
Item ER-0ICV2005AXV
Manufacturer no. 0ICV2005AXV
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Ersa i-CON VARIO 2 MK2 is an antistatic ESD 2-channel soldering and hot-air station with an integrated vacuum pump. Built for the highest demands in professional soldering and desoldering, it lets two Ersa tools run simultaneously with hot air and vacuum. The bundle includes the ergonomic i-Tool AIR S hot-air tool (200 W) for contactless energy transfer and the X-Tool vario (150 W) for desoldering leaded components.

All soldering tools feature an acceleration sensor that activates an automatic standby mode (150-300 °C) or a sleep function (room temperature) once the tool is set down. Moving the tool brings it back to operating temperature within seconds. Every function, including air and vacuum generation, is integrated into one central supply unit with simple i-OP operation and clear displays. The station provides interfaces for automatically switching on Ersa solder-fume extraction units, for controlling Ersa infrared preheaters, plus a USB port and a microSD slot for updates. It is ideally suited for use in ESD protected areas.

Technical data

FeatureValue
Antistatic designYes
Digital displayYes
Input / output230 V~ / 24 V~
Max. power200 W (360 W short-term)
Air flow2-20 l/min
Vacuummax. 700 mbar
Temperature range150-450 °C (50-550 °C i-Tool AIR S)
Max. tip temperature450 °C
Resistance tip to ground<2 Ohm
Standby power consumptionapprox. 25 W
Replacement desoldering iron0740EDJ
Soldering/desoldering tip0742ED1225H (series 742)
Tip diameter1.20 mm
Control station dimensions180 x 280 x 115 mm, approx. 6 kg
Front connectionsMains switch, i-OP push/turn dial, 2 tool ports with vacuum and pressure, microSD slot
Rear connections230 V~ IEC inlet, 2x RS232, 1x USB, air inlet with filter, 4 mm equipotential bonding socket
Weight8.12 kg
ManufacturerErsa
Manufacturer Nr.0ICV2005AXV
EAN4003008153828
GPSR manufacturer informationErsa GmbH, Leonhard-Karl-Straße 24, DE-97877 Wertheim, www.kurtzersa.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
ESD versionESD (antistatic)
Power (W)200 W
Tip diameter/width [mm]1.2
Series742
Temperature (max.)up to 450 °C

Scope of delivery

  • 0ICV2035AP i-CON VARIO 2 control station, 200 W, antistatic, with 230 V mains cable
  • 0470ERJ i-Tool AIR S hot-air tool, 24 V, 200 W, antistatic, with hot-air nozzle 0472ER 3.5 mm round
  • 0A55 holder stand for i-Tool AIR S, antistatic
  • 0740EDJ X-Tool vario desoldering iron, 24 V, 150 W, antistatic, with desoldering tip 0742ED1225H 1.2 mm inner
  • 0A56 holder stand for X-Tool vario
