XL exchange frame for holding large PCBs up to 535 x 300 mm (+x) in the Ersa HR600 hybrid rework system. Enables quick board changes and secure fixturing of large-format assemblies during rework.
PCB Exchange Frame XL, 535 x 300 mm (+x), for HR600 - Ersa 0HR635
ERSA
Original product
Net price (excl. VAT)
€2,835.00
Item
ER-0HR635
Manufacturer no.
0HR635
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.0HR635
Country of originGermany
ConditionNew
Article
ER-0HR635
Frequently Bought Together
-
This Item:
€2,835.00
-
Hold-Down Device with 3 Pins for HR 600 XL - Ersa 0HR626XL
€976.50
-
Split Optics Cassette for PL 500 A, PL 550 A Placement Systems - Ersa 0PL500A-SPC
€2,215.50
Total price
The ERSA PCB exchange frame XL holds printed circuit boards up to a format of 535 x 300 mm (+x) and is designed for use in the Ersa HR600 hybrid rework system. As an interchangeable frame, it allows quick board changes and secure fixturing of large-format assemblies during the rework process.
Technical data
| Type | PCB exchange frame XL |
|---|---|
| Board format | 535 x 300 mm (+x) |
| Suitable for | Ersa HR600 hybrid rework system |
| Manufacturer part number | 0HR635 |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 0HR635 |
| Manufacturer | Ersa |
| Country of Manufacture | Germany |
| ESD equipment | ESD Lötstationen |
| Weight | 0.100000 |
| GPSR manufacturer information | Ersa GmbH, Leonhard Karl Str. 24, DE-97877 Wertheim, www.kurtzersa.de |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
