SPLIT optics cassette for the Ersa PL 500 A and PL 550 A precision placement systems. The split-beam optics show the component and the PCB landing site at the same time for accurate, repeatable alignment. Genuine Ersa accessory.

SPLIT Optics Cassette for PL 500 A, PL 550 A Placement Systems - Ersa 0PL500A-SPC

Name: SPLIT Optics Cassette for PL 500 A, PL 550 A Placement Systems - Ersa 0PL500A-SPC
Brand: Ersa
SKU: ER-0PL500A-SPC
Price: 2215.5 EUR
Availability: InStock

ERSA Original product

Net price (excl. VAT)

€2,215.50

Excl. 19% VAT , excl. Shipping Cost

Available Fast shipping

Item ER-0PL500A-SPC

Manufacturer no. 0PL500A-SPC

Personal expert advice

Brand new Specialist dealer since 2009 Original product Worldwide shipping

Product data

Manufacturer no.0PL500A-SPC

Country of originGermany

ConditionNew

Article

ER-0PL500A-SPC

Frequently Bought Together

This Item: SPLIT Optics Cassette for PL 500 A, PL 550 A Placement Systems - Ersa 0PL500A-SPC
€2,215.50
Excl. 19% VAT , excl. Shipping Cost
Tape Feeder Base Assembly - Ersa 365840
€960.75
Excl. 19% VAT , excl. Shipping Cost
BONKOTE Replacement Tip with Nylon Brush for Flux-PEN Flux Pen - Ersa 0FMPEN-SP
€8.96
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

SPLIT optics cassette for the Ersa PL 500 A and PL 550 A precision placement systems. The split-beam optics project the component to be placed and its landing site on the PCB into the same image, so both can be aligned exactly on top of each other. This allows even fine-pitch components to be positioned precisely and repeatably.

Technical data

Type	SPLIT optics cassette (accessory)
Function	Split optics for accurate component alignment
Compatible systems	Ersa PL 500 A, PL 550 A
Manufacturer	Ersa
Article number	0PL500A-SPC

Information

More Information
Execution	TEC
Manufacturer Nr.	0PL500A-SPC
Manufacturer	Ersa
Country of Manufacture	Germany
ESD equipment	ESD Lötstationen
Weight	0.100000
GPSR manufacturer information	Ersa GmbH, Leonhard Karl Str. 24, DE-97877 Wertheim, www.kurtzersa.de
Article authenticity	Original product
Condition of article	New
