Counting Scale 60 kg / 150 kg Readability 0,02 kg / 0,05 kg - KERN IFS 100K-2M

The KERN IFS 100K-2M counts identical parts quickly and reliably instead of tallying them one by one, with a weighing range up to 150 kg and 0,02 kg readability. A numeric keypad and three separate displays turn reference sampling, piece counting and stocktaking into routine.

Benefits

• High counting resolution: up to 60.000 points for reliable piece-count determination.
• Convenient numeric keypad: direct entry of tare, reference and limit values on the ergonomic indicator.
• Three clear displays: weight, reference weight and total piece count visible at the same time.
• Automatic reference optimization: gradually refines the average piece weight for more accurate counting.
• Multi-range scale: switches automatically between 60 kg at 0,02 kg and 150 kg at 0,05 kg.
• Optionally verifiable (class III, e = 0,02 kg): for legal-for-trade use.

Technical data

• Weighing range (Max): 60 kg; 150 kg
• Readability (d): 0,02 kg; 0,05 kg
• Verification value (e): 0,02 kg; 0,05 kg
• Accuracy class: III
• Minimum capacity (Min): 0,4 kg; 1 kg
• Repeatability: 0,02 kg; 0,05 kg
• Linearity: ± 0,02 kg; 0,05 kg
• Smallest piece weight (laboratory conditions): 2,5 g
• Smallest piece weight (normal conditions): 25 g
• Weighing system: Strain gauge
• Stabilization time: 2 s
• Weighing plate (W×D): 500×400 mm
• Display digit height: 16,5 mm
• Interfaces: RS-232 as standard
• Operating temperature: -10 °C to 40 °C
• Net weight: 12 kg

Applications

Typical uses of the KERN IFS 100K-2M include plastics processing, warehouse logistics, shipping, counting applications as well as order picking and stocktaking.

Compliance and origin

EAN 4045761150973, customs tariff code 84238220, country of origin China. For legal-for-trade use, the KERN IFS 100K-2M is optionally available in accuracy class III.
