TUBELED_40 II Basic-Line LED machine light 715 mm, 15,4 W, 5700K, IP69K - LED2WORK 118410-06
Rugged budget Basic-Line machine light delivering 2374 lm at 15,4 W and 5700K. Just 29 mm low-profile, IP67/IP69K, oil-resistant and chip-impact-proof where reliable lighting without top performance is enough.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The TUBELED_40 II Basic-Line extends the established TUBELED_40 II with a budget variant of near-identical design and field robustness. It delivers 2374 lm at 15,4 W and fits anywhere a rugged machine light with reduced performance demands is needed.
Key benefits
- 2374 lm at 15,4 W and 5700K for bright illumination of work areas
- Only 29 mm low-profile, ideal where installation space is tight
- IP67/IP69K, oil-resistant and chip-impact-proof for continuous machine duty
- Shatter-resistant safety glass and aluminium housing, 100° beam angle
- Colour rendering Ra >80, made in Germany
Applications
Used to light machine tools, CNC machining centres, lathes and milling machines as well as special-purpose equipment, in new builds and retrofits alike.
Certifications: CE, UKCA. Risk group per DIN EN 62471: exempt group. Made in Germany.
Technical data
| Model | TUBELED_40 II Basic-Line |
|---|---|
| Design | LED surface-mounted machine light |
| Light source | SMD LED |
| Power | 15,4 W |
| Luminous flux | 2374 lm |
| Luminous efficacy | 155 lm/W |
| Light colour | 5700K 3-step MacAdam |
| Colour rendering (Ra) | >80 |
| Light distribution | Direct |
| Supply voltage | 24V DC * |
| Connection | M12 A-coded |
| Number of pins | 3 |
| Protection rating (IP) | IP67/IP69K |
| Protection class | III |
| Glare control | Diffuser, toughened safety glass |
| Beam angle | 100° |
| Operating temperature | -20 °C - +50 °C |
| Service life | > 60.000 h (L70/B50) |
| Housing material | Aluminium |
| Cover material | Safety glass, 4 mm |
| Dimensions | 715 mm x 40 mm x 29 mm |
| Weight | 890 g |
| Risk group (DIN EN 62471) | Exempt group |
| Dimmable | No |
| Certifications | CE, UKCA |
| Made in | Germany |
| Manufacturer | LED2WORK |
| Manufacturer Nr. | 118410-06 |
| HS-Code | 94059900 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN EN 62471 |
| Control and dimming | Dimmable |
| Luminous flux (lumen) | 2374 lm |
| Power (W) | 15.4 W |
| Colour temperature | 5700K |
| Operating voltage | 24 V |
| Protection class (IP) | IP69K |
Downloads
User Manual
Catalogue
