TUBELED_40 II Basic-Line Machine Light 540 mm, 11,6 W, 5700 K, 100° - LED2WORK 118310-06
TUBELED_40 II Basic-Line LED machine light delivering 1785 lm at 11,6 W over a 540 mm length. Low-profile, oil-resistant and chip-impact-proof with IP67/IP69K protection, made in Germany.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The TUBELED_40 II Basic-Line is the rugged budget version for work areas with reduced output needs, delivering 1785 lm at 11,6 W over a 540 mm length. Its design and durability closely match the standard model.
Your benefits
- Luminous efficacy of 155 lm/W lm/W for efficient operation
- IP67/IP69K protection, oil-resistant and resistant to coolants and lubricants
- Low-profile design at just 29 mm build height
- Shatterproof safety glass with diffuser for low-glare light
- Long service life of more than 60,000 h (L70/B50)
Applications
For bright illumination of work areas in machine tools, CNC machining centres and equipment, as original equipment or for retrofitting.
Technical data
| Model | TUBELED_40 II Basic-Line |
|---|---|
| Design | LED surface-mounted machine light |
| Light source | SMD LED |
| Power | 11,6 W |
| Luminous flux | 1785 lm |
| Luminous efficacy | 155 lm/W |
| Light colour | 5700K 3-step MacAdam |
| Colour rendering (Ra) | >80 |
| Beam angle | 100° |
| Supply voltage | 24V DC * |
| Connection | M12 A-kodiert, 3-pin |
| Protection rating | IP67/IP69K |
| Protection class | III |
| Operating temperature | -20 °C to +50 °C |
| Service life | > 60.000 h (L70/B50) |
| Housing | aluminium |
| Cover | Sicherheitsglas, 4 mm |
| Dimensions | 540 mm x 40 mm x 29 mm |
| Weight | 650 g |
| Risk group (DIN EN 62471) | exempt group |
| Certifications | CE, UKCA |
| Made in | Germany |
| Manufacturer | LED2WORK |
| Manufacturer Nr. | 118310-06 |
| HS-Code | 94059900 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN EN 62471 |
| Luminous flux (lumen) | 1785 lm |
| Power (W) | 11.6 W |
| Colour temperature | 5700K |
| Mounting type | Surface-mounted |
| Operating voltage | 24 V |
| Protection class (IP) | IP69K |
