TUBELED_40 II Basic-Line LED machine light 1540 mm, 5355 lm, IP69K - LED2WORK 118610-06

The TUBELED_40 II Basic-Line extends the established TUBELED_40 II with an affordable variant at a reduced power level. Its design and application ruggedness almost match the standard model, delivering 5355 lm from 34.6 W over a 1540 mm length.

Your benefits

• Economical solution with 5355 lm from 34.6 W and 155 lm/W
• Daylight-white 5700K light with Ra >80 colour rendering
• IP67/IP69K rating, resistant to oil and coolant and safe against flying chips
• Shatterproof safety glass (ESG) and aluminium housing
• Low 29 mm build height
• Service life of over 60,000 h (L70/B50)

Technical data

• Model: TUBELED_40 II Basic-Line
• Type: LED surface-mounted machine light
• Light source: SMD LED
• Power: 34.6 W
• Luminous flux: 5355 lm
• Luminous efficacy: 155 lm/W
• Light colour: 5700K 3-step MacAdam
• Colour rendering: Ra >80
• Beam angle: 100°
• Supply voltage: 24V DC
• Connection: M12 A-coded, 3-pin
• Protection rating: IP67/IP69K
• Protection class: III
• Operating temperature: -20 °C to +50 °C
• Service life: > 60,000 h (L70/B50)
• Housing: aluminium
• Cover: safety glass, 4 mm
• Dimensions: 1540 mm x 40 mm x 29 mm
• Weight: 2020 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA
• Made in: Germany

Applications

Suited to application areas where a rugged machine light is required but at a reduced power level, such as CNC and machine tools. Not dimmable and not cascadable. An undervoltage supply below 24V DC reduces the luminous flux.
