TUBELED_40 II ECO LED machine light 1540 mm, 6750 lm, cascadable - LED2WORK 118610-12

The TUBELED_40 II ECO in cascadable form lights working areas inside machines in daylight white, delivering 6750 lm from around 39 W at just 29 mm mounting height. An extra output and M12 connector let you daisy-chain several luminaires of this series electrically.

Your benefits

• Efficient efficacy of around 173 lm/W at only ~39 W
• Cascadable up to a total current draw of max. 4 A at 40 °C
• Daylight-white 5700K light with Ra >85 colour rendering
• IP67/IP69K rating, resistant to oil and coolant and safe against flying chips
• High-temperature design up to +70 °C, shatterproof safety glass (ESG)
• Long service life of over 100,000 h (L80/B10)

Technical data

• Model: TUBELED_40 II ECO, cascadable
• Type: LED surface-mounted machine light
• Light source: SMD LED
• Power: ~39 W
• Luminous flux: 6750 lm
• Luminous efficacy: ~173 lm/W
• Light colour: 5700K 3-step MacAdam
• Colour rendering: Ra >85
• Beam angle: 100°
• Supply voltage: 24V DC ± 10%
• Connection: M12 A-coded
• Protection rating: IP67/IP69K
• Protection class: III
• Operating temperature: -30 °C to +70 °C
• Service life: > 100,000 h (L80/B10)
• Housing: aluminium
• Cover: safety glass, 4 mm
• Dimensions: 1540 mm x 40 mm x 29 mm
• Weight: 2020 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA, ETL Listed (5003529), D mark
• Made in: Germany

Applications

For economical lighting of working areas in CNC and machine tools, for first fit and retrofit. Several luminaires can be daisy-chained by cascading. Dimmable optionally via accessory.
