Bending ring load cell 60 kg / 600 N, stainless steel, C3 - SAUTER CR 60-3P1
Bending ring load cell SAUTER CR 60-3P1 made of stainless steel for compressive forces up to 600 N or loads up to 60 kg. Verifiable to OIML class C3 with 3000 e, IP68 protection and a 3 m cable with 4-wire connection. Suited to weighbridges, hanging scales, silo scales and test stands.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The SAUTER CR 60-3P1 measures weight and compressive force up to 60 kg or 600 N in a flat bending ring design. Load is applied through a customer-side thrust piece with 15 mm diameter in the central bore, and the cell is fixed with three M5 threaded holes. This keeps the installation height low in scales and test stands.
Advantages
- Verifiable to OIML C3: 3000 e with a combined error of 0.023 %, suitable for building legal-for-trade scales.
- Bending ring design: central force application and simple mounting via three M5 threads.
- IP68 and stainless steel: for use in damp or dusty environments, for example in agriculture and manufacturing.
- 3 m cable: the evaluation unit can be mounted away from the measuring point.
- Matching evaluation: can be combined with the DIN rail evaluation unit KERN CE HSN and the SAUTER FS 2 series force gauges.
Applications
Measurement of mass and compressive force in weighbridges, hanging scales, silo scales and other scales as well as in test stands. Main fields of application are industry and manufacturing, agriculture and test stand construction.
Conformity and origin
EAN 4045761226883. Warranty 36 months.
Technical data
| Weighing capacity (Max) | 60 kg |
|---|---|
| Force measuring range (Max) | 600 N |
| Design | bending ring |
| Direction of force | compression |
| Measuring applications | force, mass |
| Combined error | 0.023 % |
| OIML class | C3 |
| Resolution (verifiable) | 3000 e |
| Y-value | 10000 |
| Nominal output | 1 mV/V |
| Protection class | IP68 |
| Material | stainless steel |
| Connection | 4-wire |
| Cable length | 3 m |
| Force application | thrust piece D=15 mm in bore (customer side) |
| Force dissipation | 3 x threaded hole M5 |
| Manufacturer | Sauter |
| EAN | 4045761226883 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
