Extraction hose DN50, PE 2000, 1 m with end piece - ULT 06.1.002
Grey PE 2000 extraction hose with 50 mm tube diameter, cut to 1 m and fitted with an end piece. Connects ULT WSA-5LR, WSA-10LR and WSA-20LR extractors to the workstation and carries solder fume safely to the filter unit. Reach up to 1000 mm, for ceiling, bench and wall mounting.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Extracting at several or spread-out soldering stations calls for a flexible link between the capture point and the filter unit. This grey DN50 extraction hose in PE 2000 is cut to 1 m and fitted with an end piece and carries solder fume reliably to the ULT WSA-LR extractors.
Benefits
- 50 mm tube diameter (DN50) matching the ports of the WSA-5LR, WSA-10LR and WSA-20LR.
- PE 2000 is light, dimensionally stable and chemically resistant to solder fume constituents.
- Reach up to 1000 mm bridges the gap between unit and soldering point.
- Suitable for ceiling, bench and wall mounting, so it fits varied workstation layouts.
- Factory-fitted with an end piece, ready to mount.
Applications
Extraction of solder fume at manual soldering stations, in electronics manufacturing, repair and prototyping, connected to a ULT WSA-LR filter unit.
Compatibility & scope of delivery
Fits the ULT extractors WSA-5LR, WSA-10LR and WSA-20LR. Scope of delivery: one DN50 extraction hose in PE 2000 in 1 m length with end piece.
Manufactured by ULT AG, Germany. ESD-compliant accessory for conductive extraction systems.
Technical data
| Artikel-Nr. | WL18653 |
|---|---|
| Hersteller-Artikel-Nr. | 06.1.002 |
| Hersteller | ULT |
| Rohrdurchmesser | 50 mm (DN50) |
| Material | Kunststoff PE 2000 |
| Farbe | grau |
| Reichweite | 1000 mm |
| Endstück | ja |
| Verkaufseinheit | Stück |
| Montageart | Deckenmontage, Tischmontage, Wandmontage |
| Geräteserie | WSA-5LR, WSA-10LR, WSA-20LR |
| Weight | 0.100000 |
| Manufacturer | ULT |
| Manufacturer Nr. | 06.1.002 |
| HS-Code | 39173900 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | ESD (antistatic) |
| Nennweite DN [mm] | 50 |
| Länge [mm] | 1000 |
