Solder fume extractor 2 intake ports DN50, 80 m³/h at 1900 Pa, H13A - WSA-5LR
Solder fume is a mix of sticky aerosols, particles and gases that a single filter stage cannot handle. The WSA-5LR therefore filters through an M5/F7 filter mat and an H13A combination cassette with an activated carbon bed, reaching a particle separation rate of 99.95 percent. Two DN50 intake ports serve 1 to 2 workstations with 80 m³/h at 1900 Pa.
Net
excl. VAT
€1,383.93
Item
WL37325
Manufacturer no.
WEID 0160.1-MD.11.02.6023
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Soldering releases flux vapour, solder particles and outgassing substances from boards and components. The WSA-5LR extraction unit separates that load in several stages and provides a nominal volume flow of 80 m³/h at 1900 Pa across two DN50 intake ports.
Benefits
- Upstream M5/F7 filter mat combination retains cooled, sticky aerosols and prevents premature clogging of the H13 main filter
- H13A combination cassette with high efficiency particulate filter and activated carbon bed, particle separation rate of 99.95 percent
- Steplessly adjustable volume flow from an EC blower with high pressure reserve, up to 190 m³/h and 3200 Pa
- Two DN50 intake ports serve 1 to 2 workstations from one unit
- Optical filter indicator and maintenance-free EC drive
- Four adjustable blow-out gills on both sides at the bottom, noise level 45-49 dBA
- Recirculation mode returns the cleaned air to the working area without heat loss
Applications
Extraction and filtration of solder fume, gases and vapours in non-explosive air mixtures at hand soldering, repair and test benches. Recirculation mode is not permitted for the extraction and filtration of carcinogenic, mutagenic or reprotoxic substances.
Compatibility and scope of delivery
Supplied as the WSA-5LR extraction unit with M5/F7 filter mat and H13A combination filter cassette. Extraction hoses connect to the two DN50 ports on the top. Changing the M5/F7 filter fleece combination regularly at shorter intervals significantly extends the service life of the main filter. Hoses, nozzles and replacement filters are ordered separately.
Technical data
| Item number | WL37325 |
|---|---|
| Model | WSA-5LR |
| Manufacturer item number | WEID 0160.1-MD.11.02.6023 |
| Order unit | Piece |
| Dimensions (LxWxH) | 400 mm x 350 mm x 420 mm |
| Voltage | 230 V |
| Frequency | 50/60 Hz |
| Nominal current | 0.95 A |
| Motor rating | 0.15 kW |
| Nominal volume flow | 80 m³/h at 1900 Pa |
| Volume flow max | 190 m³/h |
| Vacuum max | 3200 Pa |
| Noise level | 45-49 dBA |
| Intake ports | 2 x DN50, outer diameter 50 mm, top |
| Air outlet | Blades on both sides, adjustable |
| Filter | Filter mat M5/F7, combination filter cassette H13A |
| Particle separation rate | 99.95 percent |
| Equipment | Maintenance-free EC blower, particle filter occupancy indicator |
| Colour | RAL 7035 |
| Workstations | 1 to 2 |
| Weight | 30.000000 |
| Manufacturer | A1-ESD |
| Manufacturer Nr. | WEID 0160.1-MD.11.02.6023 |
| HS-Code | 84213925 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
