RxP series Quad rework tip that reflows all four sides of a QFP 100 package in a single step. Fits the MFR-H1-SC handpiece of the Oki MFR-1100 and MFR-2200 stations.
Rework tip RxP Quad for QFP 100, MFR-1100/2200 - Oki RFP-QD20
OKI
Original product
Net price (excl. VAT)
€109.87
Item
WL24751
Manufacturer no.
RFP-QD20
Zertifiziert nach
ESD · IEC 61340-5-1
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.RFP-QD20
Country of originUnited States
Customs tariff number85159080900
ConditionNew
Article
WL24751
Frequently Bought Together
-
This Item:
€109.87
-
Soldering tip SxP Serie hoof-shaped 3,5x17,78 mm for MFR - Oki STP-DRH35
€28.07
-
Soldering tip SxV series conical long 1x18 mm, 460 °C - Oki SCV-CNL10A
€12.06
Total price
The RxP Quad tip RFP-QD20 is designed for removing and re-placing QFP 100 packages. It surrounds the component on all four sides so every pin reaches soldering temperature at the same time and the part can be lifted without stressing the board.
Key benefits
- Quad geometry for QFP 100: reflows all four pin rows in one step
- SmartHeat control of the MFR handpiece keeps tip temperature stable without calibration
- quick exchange on the MFR-H1-SC handpiece for different package sizes
Technical data
| Item no. | WL24751 |
| Manufacturer no. | RFP-QD20 |
| Manufacturer | OKI / Metcal |
| Product series | RxP |
| Tip shape | Quad |
| Suitable for | QFP 100 |
| Compatible handpiece | MFR-H1-SC / MFR-H1-SC2 |
| Compatible systems | MFR-1100, MFR-2200 |
| Order unit | Stück / piece / pièce |
Applications
Rework and repair of surface-mount QFP 100 packages in electronics manufacturing and laboratory use.
Compatibility and scope of delivery
- Handpiece MFR-H1-SC / MFR-H1-SC2
- Oki MFR-1100 and MFR-2200 series stations
- Supplied: 1 piece
Suitable for ESD-safe use per IEC 61340-5-1. Origin USA.
| Certification | IEC 61340-5-1 |
|---|---|
| ESD version | ESD (antistatic) |
| Manufacturer Nr. | RFP-QD20 |
| Manufacturer | Oki |
| Country of Manufacture | United States |
| Weight | 0.100000 |
| HS-Code | 85159080900 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
