Programmable convection preheater with 1200 W heating power and a 25-400 °C range that brings assemblies evenly up to temperature before rework. Four zones combine time and temperature into complete heat profiles and 50 profiles can be stored. Controlled cooling protects board and components against thermal shock.
Programmable preheater 25-400 °C, 1200 W, 4 zones - Oki PCT-1000
OKI Original product
Net price (excl. VAT)
€1,807.47
Item WL25118
Manufacturer no. PCT-1000
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.PCT-1000
ConditionNew
Article
WL25118
Frequently Bought Together
- This Item: €1,807.47
- Digital hot air rework station 200 W, 100-450 °C, 6 nozzles - Oki HCT2-200-21 €614.71
- Programmable hot air rework station 600 W up to 450 °C with HCT-HV1 handpiece - Oki HCT-1000 €2,422.17
Total price
When large SMD packages are removed or fitted, the board pulls heat away from the joint. The PCT-1000 is a programmable preheater with 1200 W and a 25-400 °C control range that raises the assembly to profile temperature from below, so the joint itself needs less peak temperature.
Benefits
- 1200 W heating power and 25-400 °C range for soldering, desoldering and SMD rework
- Programmable 4-zone settings for time and temperature to build complete heat profiles
- Memory for 50 user-defined profiles
- Control either at source (internal) or at destination (external) via type K thermocouple
- Controlled cooling prevents thermal shock on boards and components
- Vortex heating design with 538 LPM air flow for even heat distribution
Technical data
| Item number | WL25118 |
| Model | PCT-1000 |
| Manufacturer | OKI |
| Manufacturer item number | PCT-1000 |
| Order unit | piece |
| Nominal power | 1200 W |
| Voltage | 100-240 V |
| Temperature range | 25-400 °C |
| Air flow | 538 LPM |
| Profile memory | 50 user-defined profiles |
| Zones | 4, each with time and temperature |
| Display | 20 x 4 display segments |
| Scope of supply | Programmable preheater, type K T/C kit, foot switch, power cord, user manual |
| Weight | 0.1 kg |
Applications
Rework on BGA, QFN and large-area SMD packages, desoldering on multilayer boards with high thermal mass, repair of power electronics, and process development where repeatable heat profiles have to be documented.
Compatibility and scope of delivery
The preheater works stand-alone or together with hand soldering and hot air systems. Delivery includes the programmable preheater, the type K thermocouple kit, a foot switch, the power cord and the user manual. The universal power supply accepts 100-240 V.
| Manufacturer Nr. | PCT-1000 |
|---|---|
| Manufacturer | Oki |
| Weight | 0.100000 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
