Crimping die set for coax connectors RG 58 to RG 71, hexagon 5.4 / 6.48 / 1.72 mm - Knipex 97 49 40

A coax connector only stays tight if the sleeve is crimped to the correct hexagon size. The 97 49 40 crimping die set provides three sizes for that job, 5.4 mm, 6.48 mm and 1.72 mm, and is fitted into the KNIPEX crimp system pliers of the 97 43 xx series.

Benefits

• Three dies in one insert, hexagonal crimping capacity 5.4 mm, 6.48 mm and 1.72 mm.
• Covers coax connectors of the types RG 58, RG 59, RG 62 and RG 71, according to the data sheet also RG 223.
• Matches sleeves of 6.4, 7.6 and 2.1, so outer conductor and inner contact are crimped with the same insert.
• Exchangeable die set for the KNIPEX crimp system pliers 97 43 xx, the pliers stay in use and only the profile changes.
• Compact at 50 x 17 mm and 57 g, easy to keep as a spare in the case of the system pliers.

Technical data

Areas of use

Antenna and satellite technology, video and network technology and measuring equipment, wherever BNC, TNC and comparable connectors are fitted to coax cables of the types RG 58 to RG 71.

Standards and conformity

According to the manufacturer the die set contains substances of very high concern under the REACH regulation. The RoHS directive does not apply to this product.
